约翰迪尔零件查询410D - BACKHOE, LOADER DIFFERENTIAL ASSEMBLY WITH RING GEAR AND PINIONEPC John Deere online

广数供应链运营团队, 16 02月, 2025，浏览： 542 次

Pos.	Part No	Qty	Parts name	Comments
1.	T22874	[10]	Bolt
2.	T21433	[1]	Bearing Housing W/O Bearing
3.	T21434	[AR]	Shim	0.08 MM (.003")
3.	T21435	[AR]	Shim	0.13 MM (.005")
3.	T21436	[AR]	Shim	0.25 MM (.010")
4.	JD7425	[1]	Bearing Cup
5.	JD8147	[1]	Bearing Cone
6.	T21596	[1]	Brake Drum
7.	T21430	[8]	Cap Screw
8.	T21974	[1]	Housing
9.	T118949	[2]	Bevel Gear
10.	T118950	[4]	Bevel Gear
11.	T21875	[2]	Pinion Shaft
12.	T30253	[1]	Housing	(ALSO ORDER (8) T30254)
12.	T149743	[1]	Housing	(ALSO ORDER (8) T152922)
13.	T30254	[8]	Rivet	11.125 X 42.875 MM (7/16" X 1-11/16")
13.	T152922	[8]	Rivet	1/2" X 1 5/8"
14.	AT166889	[1]	Housing	(CONTAINS T149743 AND (8) T152922 ) (SUB FOR AT146046)(MARKED T30253) (WITH SPIRAL BEVEL GEAR MARKED T149745) (35 TEETH) AND (BEVEL PINION SHAFT, MARKED T135019) (8 TEETH) (SUB FOR AT146046) (MARKED T30253) (WITH SPIRAL BEVEL GEAR MARKED T21401) (35
14.	AT164294	[1]	Housing	(CONTAINS T149743 AND (8) T152922)(MARKED T30253) (WITH SPIRAL BEVEL GEAR MARKED T149745) (35 TEETH) AND (BEVEL PINION SHAFT, MARKED T148347) (8 TEETH)
15.	JD8946	[1]	Bearing Cone
16.	T21432	[1]	Bearing Housing W/O Bearing
17.	JD8206	[1]	Bearing Cup
18.	T71306	[1]	Orifice
18.	15H558	[1]	Pipe Plug	1/8"
