| Pos. | Part No | Qty | Parts name | Comments |
|---|---|---|---|---|
| 1. | T148381 | [1] | Counterweight | CONVENIENCE ASSEMBLY (400 LB) |
| 2. | ........ | [1] | Counterweight | (750 LB) ( T148382 NO LONGER AVAILABLE) (USE WITH AT169181 AND T152677) |
| 3. | T119912 | [4] | Washer | 16.660 X 41.148 X 6 MM (21/32" X 1.620" X 0.236") |
| 4. | 19M7882 | [4] | Screw | M16 X 170 |
| 5. | ........ | [1] | Counterweight | ( AT169181 NO LONGER AVAILABLE (450 LB) (USE WITH T148382 ) (ALSO ORDER (2) 19M8415, (4) 24M7242 AND (2) 14M7277) |
| 6. | T152677 | [1] | Counterweight | CONVENIENCE ASSEMBLY (250 LB) (USE WITH T148382 ) (ALSO ORDER (2) 19M8415 OR (2) 19M8411, (4) 24M7242 AND (2) 14M7277) |
| 7. | 24M7242 | [4] | Washer | 21.400 X 42 X 5 MM |
| 8. | 19M8415 | [2] | Cap Screw | M20 X 260 (USE WITH AT169181 OR T152677) |
| 8. | 19M8411 | [2] | Screw | M20 X 340 (USE WITH AT169181 AND T152677) |
| 9. | 14M7277 | [2] | Nut | M20 |
