| Pos. | Part No | Qty | Parts name | Comments |
|---|---|---|---|---|
| 1. | ........ | [1] | Fender | RIGHT OUTER T146009 NO LONGER AVAILABLE (SUB FOR T85312 ) (SUB T158623, T158624, (24) 24M7100 AND (24) 19M7933) |
| 1. | ........ | [1] | Fender | LEFT OUTER T146010 NO LONGER AVAILABLE (SUB FOR T85313 ) (SUB T158623, T158624, (24) 24M7100 AND (24) 19M7933) |
| 2. | 24M7118 | [6] | Washer | 18 X 25 X 1 MM (SUB FOR T134611 ) (SUB FOR T141798, THIS APPLICATION) |
| 3. | T151864 | [8] | Screw | M6 X 20 (SUB FOR T133289) |
| 4. | 24H1122 | [6] | Washer | 3/8" X 7/8" X 0.083" |
| 5. | T151863 | [4] | Bolt | M6 X 24 (SUB FOR T133288) |
