约翰迪尔零件查询410D - BACKHOE, LOADER Extendible Dipperstick Cylinder Hydraulic Line, Pins And Stop (For Use With 1.5M Extendible DipppersEPC John Deere online
广数供应链运营团队, 16 02月, 2025，浏览：
236 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
T77857
|
[1] |
O-Ring
|
|
| 2. |
AT161678
|
[1] |
Elbow Fitting
|
|
| 3. |
R26375
|
[1] |
O-Ring
|
|
| 4. |
T77857
|
[2] |
O-Ring
|
|
| 5. |
AT159058
|
[1] |
Tube
|
|
| 6. |
AR21842
|
[1] |
Clamp
|
|
| 7. |
T101624
|
[1] |
Support
|
|
| 8. |
38H1173
|
[1] |
Adapter Fitting
|
|
| 9. |
R26448
|
[1] |
O-Ring
|
|
| 10. |
28H1883
|
[1] |
Spacer
|
|
| 11. |
T24958
|
[1] |
Clip
|
|
| 12. |
24M7238
|
[1] |
Washer
|
|
| 13. |
19M7932
|
[1] |
Cap Screw
|
|
| 14. |
........
|
[1] |
Hydraulic Cylinder Barrel
|
|
| 15. |
L1610N
|
[4] |
Snap Ring
|
|
| 16. |
T143262
|
[1] |
Pin
|
|
| 17. |
T145377
|
[1] |
Pin
|
|
| 18. |
AH141803
|
[1] |
Hydraulic Cylinder Rod
|
|
| 19. |
14M7273
|
[1] |
Nut
|
|
| 20. |
24M7238
|
[6] |
Washer
|
|
| 21. |
AT161938
|
[1] |
Stop
|
|
| 22. |
19M7922
|
[1] |
Cap Screw
|
|
| 23. |
14M7166
|
[1] |
Lock Nut
|
|
