约翰迪尔零件查询410D - BACKHOE, LOADER Controlled Lowering Devise, Boom Cylinder Kit 410D Heavy Lift, 510D Standard)EPC John Deere online

广数供应链运营团队, 16 02月, 2025，浏览： 639 次

Pos.	Part No	Qty	Parts name	Comments
1.	AT171833	[1]	Hyd Actuated Control Valve
2.	AT173883	[1]	Hyd Actuated Control Valve	(AT173887 KIT, COUNTERBALANCE SEAL) COUNTERBALANCE
3.	AT173884	[1]	Manual Hydraulic Valve	(AT173888 KIT, NEEDLE SEAL) NEEDLE
4.	R26448	[2]	O-Ring
5.	AT173909	[1]	Hose
6.	H165693	[2]	Screw	M6 X 12 (SUB FOR H130192)
7.	38H1004	[1]	Elbow Fitting
8.	T77613	[2]	O-Ring
9.	AT167148	[1]	Hydraulic Hose	17.4752" X 361 MM (14-1/4") X 17.4752"
10.	AT176162	[1]	Bracket
11.	TY22495	[1]	Hose Clamp
12.	T105773	[1]	Guide
13.	38H1473	[1]	Reducer
14.	T77858	[3]	O-Ring
15.	38H1356	[1]	Tube Nut
16.	38H1272	[1]	Union Fitting
17.	AT80224	[1]	Hydraulic Hose	30.1752" X 1075 MM (42-1/4") X 30.1752"
18.	T76938	[2]	O-Ring
19.	AT176228	[1]	Tee Fitting
20.	T77857	[4]	O-Ring
21.	T102005	[1]	Guide
22.	AT176530	[1]	Hose	13/16" X 299 MM (11-3/4") X 13/16"
23.	24M7241	[3]	Washer	17 X 34 X 4 MM
24.	AT171200	[1]	Oil Line
25.	38H1012	[2]	Elbow Fitting
26.	R26906	[2]	O-Ring
27.	TY22489	[1]	Hose Clamp	(SUB FOR AR85329)
28.	........	[1]	Kit	( AT170493 NO LONGER AVAILABLE)
