约翰迪尔零件查询410E - BACKHOE, LOADER Load Sense HydraulicsEPC John Deere online

广数供应链运营团队, 16 02月, 2025，浏览： 314 次

Pos.	Part No	Qty	Parts name	Comments
1.	AT171920	[1]	Hydraulic Hose - Fabricate	17.4752" X 1651 MM (65") X 17.4752"
2.	T77613	[10]	O-Ring
3.	38H1160	[5]	Adapter Fitting
4.	R26448	[7]	O-Ring
5.	AT171917	[1]	Hydraulic Hose - Fabricate
6.	38H1314	[1]	Elbow Fitting
7.	AH125760	[1]	Hyd. Quick-Connect Coupler
8.	R77175	[1]	Cover
9.	AT180915	[1]	Hose
10.	AT194937	[1]	Check Valve	(SUB FOR AT180887)
11.	R26375	[1]	O-Ring
12.	R68664	[1]	Fitting
13.	RE32361	[1]	Hose Clamp	(SUB FOR AR48236)
14.	AT175655	[1]	Hydraulic Hose - Fabricate
15.	AT194935	[1]	Tee Fitting	(W/ ORIFICE) (INCLUDES (2) T77613) (SUB FOR AT173046, THIS APPLICATION)
16.	19M8081	[2]	Cap Screw	M10 X 80
17.	24M7239	[2]	Washer	10.700 X 21 X 2.500 MM
18.	R46919	[2]	Half Clamp
18.	T160549	[2]	Clamp
19.	28H3394	[2]	Bushing	0.493" X 0.675" X 1/2"
20.	H141836	[2]	Bushing	12.522 X 17.145 X 25.400 MM (0.493" X 0.675" X 1")
21.	AT171919	[1]	Hydraulic Hose - Fabricate	17.4752" X 1102 MM (43-1/2") X 17.4752"
22.	R46819	[2]	Housing
22.	T159956	[2]	Clamp
23.	T77857	[2]	O-Ring	12.421 X 1.778 MM (0.489" X 0.070")
24.	R44302	[2]	Tie Band	(CORDURA SLEEVE)
25.	........	[1]	Sleeve	MAKE FROM BULK MATERIAL CTL
26.	T77857	[1]	O-Ring	12.421 X 1.778 MM (0.489" X 0.070") SHUTTLE CHECK ELBOW
27.	38H1095	[1]	Elbow Fitting
28.	T161464	[1]	Sleeve
29.	R44302	[1]	Tie Band
30.	AT171919	[1]	Hydraulic Hose - Fabricate	17.4752" X 1102 MM (43-1/2") X 17.4752"
