约翰迪尔零件查询410G - BACKHOE, LOADER Planetary Drive (w/ MFWD)EPC John Deere online
广数供应链运营团队, 16 02月, 2025，浏览：
607 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
L79729
|
[1] |
Ring Gear
|
|
| 2. |
T151085
|
[1] |
Sun Gear
|
|
| 3. |
L100169
|
[3] |
Snap Ring
|
|
| 4. |
AL117021
|
[3] |
Roller Bearing
|
|
| 4. |
AL79843
|
[3] |
Roller Bearing
|
|
| 5. |
T165415
|
[3] |
Planet Pinion
|
|
| 5. |
L100241
|
[3] |
Planet Pinion
|
|
| 6. |
AL117022
|
[3] |
Roller Bearing
|
|
| 6. |
AL79904
|
[3] |
Roller Bearing
|
|
| 7. |
T165416
|
[1] |
Planet Pinion Carrier
|
|
| 7. |
L100242
|
[1] |
Planet Pinion Carrier
|
|
| 8. |
19M5039
|
[2] |
Screw
|
|
| 9. |
L55580
|
[1] |
O-Ring
|
|
| 10. |
L100240
|
[1] |
Drain Plug
|
|
