久保田零件查询054000 WIRING DIAGRAM BODYEPC Kubota online
广数供应链运营团队, 16 02月, 2025，浏览：
400 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 001. |
3526034402
|
[1] |
ASSY WIRE HARNESS
|
0.0000(lbs); 0.000
|
| 002. |
3526034410
|
[1] |
WIRE HARNESS 1
|
0.8800(lbs); 0.400
|
| 003. |
3526034320
|
[1] |
WIRE HARNESS 2
|
0.3740(lbs); 0.170
|
| 004. |
3511034330
|
[1] |
WIRE HARNESS 3
|
0.0770(lbs); 0.035
|
| 005. |
3526034350
|
[1] |
WIRE HARNESS 5
|
0.2860(lbs); 0.130
|
| 006. |
3511034350
|
[1] |
CORD HEAD LAMP EARTH
|
0.0110(lbs); 0.005
|
| 007. |
0401150100
|
[2] |
WASHER PLAIN
|
0.0044(lbs); 0.002
|
| 008. |
3526034370
|
[2] |
CORD EARTH
|
0.0066(lbs); 0.003
|
| 009. |
3715034460
|
[4] |
CLAMP CORD
|
0.0088(lbs); 0.004
|
| 010. |
3415029390
|
[2] |
CLAMP CORD
|
0.0088(lbs); 0.004
|
| 011. |
3715034470
|
[1] |
CLAMP CORD
|
0.0088(lbs); 0.004
|
| 012. |
3224034482
|
[2] |
CLAMP CORD 1
|
0.0176(lbs); 0.008
|
| 013. |
3224034490
|
[5] |
CLAMP CORD 2
|
0.0066(lbs); 0.003
|
| 014. |
3415029390
|
[1] |
CLAMP CORD
|
0.0088(lbs); 0.004
|
| 015. |
3715034480
|
[1] |
CLAMP CORD
|
0.1320(lbs); 0.060
|
| 016. |
0112350814
|
[1] |
BOLT
|
0.0220(lbs); 0.010
|
| 017. |
0122250812
|
[3] |
BOLT
|
0.0154(lbs); 0.007
|
| 018. |
0451250080
|
[3] |
WASHER SPRING
|
0.0044(lbs); 0.002
|
