| Pos. | Part No | Qty | Parts name | Comments |
|---|---|---|---|---|
| 2. | 134-2561Y | [2] | CYLINDER GP-HYDRAULIC(GRADE) | |
| 3. | 177-2215 | [2] | STRAP-DUAL CLAMP | |
| 4. | 148-8378 | [8] | ELBOW AS | |
| (EACH INCLUDES) | ||||
| 3J-1907 | [1] | SEAL-O-RING | ||
| 6V-8397 | [1] | SEAL-O-RING | ||
| 6V-8724 | [1] | ELBOW | ||
| 5. | 091-9006I | [2] | HOSE AS | |
| 6. | 133-4204I | [2] | HOSE AS | |
| 9. | 154-1420BE | SLEEVE | ||
| 10. | 3S-2093 | [4] | STRAP-CABLE | |
| B | USE AS REQUIRED | |||
| E | ORDER BY THE CENTIMETER | |||
| I | REFER TO HYDRAULIC INFORMATION SYSTEM | |||
| Y | SEPARATE ILLUSTRATION | |||
