久保田零件查询T07500 DRIVE CASE FRONT AXLE AND FRONT WHEELEPC Kubota online
广数供应链运营团队, 16 02月, 2025，浏览：
964 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 010. |
3780044110
|
[1] |
CASE DRIVE
|
7.9200(lbs); 3.600
|
| 020. |
3715014150
|
[2] |
PIN STRAIGHT
|
0.2750(lbs); 0.125
|
| 020. |
0501201018
|
[2] |
PIN STRAIGHT
|
0.0264(lbs); 0.012
|
| 030. |
3780044120
|
[4] |
BOLT
|
0.2420(lbs); 0.110
|
| 040. |
3780044130
|
[1] |
COVER PTO
|
2.4420(lbs); 1.110
|
| 050. |
3780044140
|
[1] |
GASKET
|
0.0154(lbs); 0.007
|
| 060. |
0117351028
|
[4] |
BOLT
|
0.0484(lbs); 0.022
|
| 070. |
0451250100
|
[4] |
WASHER SPRING
|
0.0066(lbs); 0.003
|
| 080. |
3780044190
|
[1] |
SHAFT
|
1.3156(lbs); 0.598
|
| 080. |
3531044190
|
[1] |
SHAFT
|
1.4740(lbs); 0.670
|
| 090. |
0810106205
|
[2] |
BEARING BALL
|
0.2640(lbs); 0.120
|
| 100. |
0461100520
|
[1] |
CIR-CLIP INTERNAL
|
0.0198(lbs); 0.009
|
| 110. |
0950305211
|
[1] |
SEAL OIL
|
0.0484(lbs); 0.022
|
| 120. |
1551296010
|
[2] |
PLUG DRAIN
|
0.2222(lbs); 0.101
|
| 130. |
0471702150
|
[2] |
WASHER WITH RUBBER
|
0.0088(lbs); 0.004
|
| 140. |
3780044210
|
[1] |
SLEEVE
|
0.0330(lbs); 0.015
|
| 150. |
3531044230
|
[1] |
GEAR
|
2.7280(lbs); 1.240
|
| 160. |
3780044310
|
[1] |
LEVER SHIFT
|
0.3212(lbs); 0.146
|
| 170. |
3780044350
|
[1] |
GUIDE LEVER
|
0.0924(lbs); 0.042
|
| 180. |
3780044390
|
[1] |
RUBBER
|
0.0110(lbs); 0.005
|
| 190. |
3780044380
|
[1] |
SUPPORT LEVER
|
0.2200(lbs); 0.100
|
| 200. |
0113351020
|
[1] |
BOLT
|
0.0440(lbs); 0.020
|
| 210. |
3780044360
|
[1] |
LEVER CHANGE
|
0.0000(lbs); 0.000
|
| 210. |
3531044360
|
[1] |
LEVER CHANGE
|
0.4620(lbs); 0.210
|
| 220. |
3780044400
|
[1] |
LEVER
|
1.0890(lbs); 0.495
|
| 230. |
0541100430
|
[1] |
PIN SPRING
|
0.0044(lbs); 0.002
|
| 240. |
5420123270
|
[1] |
GRIP
|
0.0440(lbs); 0.020
|
| 250. |
0115350814
|
[1] |
BOLT
|
0.0198(lbs); 0.009
|
| 260. |
0451250080
|
[1] |
WASHER SPRING
|
0.0044(lbs); 0.002
|
| 270. |
0541100625
|
[1] |
PIN SPRING
|
0.0088(lbs); 0.004
|
| 280. |
0481100150
|
[1] |
O RING
|
0.0022(lbs); 0.001
|
| 290. |
0512251022
|
[1] |
PIN JOINT
|
0.0308(lbs); 0.014
|
| 300. |
0401350100
|
[1] |
WASHER PLAIN
|
0.0088(lbs); 0.004
|
| 310. |
0551150318
|
[1] |
PIN SPLIT
|
0.0022(lbs); 0.001
|
| 320. |
3531044900
|
[1] |
MARK
|
0.0022(lbs); 0.001
|
| 330. |
0451250120
|
[4] |
WASHER SPRING
|
0.0066(lbs); 0.003
|
