卡特零件查询（AP-1055D） 128-5626: STARTING MOTOR GP-ELECTRIC
广数供应链运营团队, 16 02月, 2025，浏览：
456 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | 3K-3257 | [1] | GASKET | |
| 2. | 8Y-9603 | [1] | CABLE AS-STARTING MOTOR | |
| | 1S-7251 | [1] | TERMINAL-CABLE(00-GA, 1/2-IN SCREW) | |
| | 1S-7252 | [1] | TERMINAL-CABLE(00-GA, 3/8-IN SCREW) | |
| | 5P-0747E | | CABLE(00-GA, BLACK)(28-CM) | |
| 3. | 118-9573M | [3] | BOLT-12 POINT HEAD(M10X1.5X35-MM) | |
| 4. | 207-1551CY | [1] | STARTING MOTOR GP-ELECTRIC | |
| 5. | 8T-4121 | [4] | WASHER-HARD(11X21X2.5-MM THK) | |
| 6. | 8T-4191M | [1] | BOLT(M10X1.5X16-MM) | |
| | C | | CHANGE FROM PREVIOUS TYPE |
| | E | | ORDER BY THE CENTIMETER |
| | M | | METRIC PART |
| | R | | REMANUFACTURED PART MAY BE AVAILABLE |
| | Y | | SEPARATE ILLUSTRATION |
