| Pos. | Part No | Qty | Parts name | Comments |
|---|---|---|---|---|
| 1. | 3S-2093 | [14] | STRAP-CABLE | |
| 2. | 4P-5918 | [1] | CLIP | |
| 3. | 105-1797 | [2] | MOUNT | |
| 4. | 198-2713Y | [1] | HARNESS AS-ENGINE(ELECTRONIC CONTROL MODULE) | |
| 5. | 206-1345 | [7] | STRAP-CABLE | |
| 6. | 519-5559 | [1] | CLIP | |
| 7. | 520-1511Y | [1] | HARNESS AS-ENGINE(FUEL INJECTOR) | |
| 8. | 4P-8134 | [1] | CLIP(LADDER) | |
| 9. | 6V-2317M | [1] | BOLT(M8X1.25X30-MM) | |
| 10. | 9M-1974 | [1] | WASHER-HARD(8.8X16X2-MM THK) | |
| M | METRIC PART | |||
| Y | SEPARATE ILLUSTRATION | |||
