卡特零件查询（AP-1055D） 230-9613: LINES GP-SCREED
广数供应链运营团队, 16 02月, 2025，浏览：
566 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | 3S-2093 | [8] | STRAP-CABLE | |
| 2. | 5R-5676 | [1] | PLUG-DUST | |
| 3. | 5R-5677 | [1] | CAP-DUST(DUST) | |
| 4. | 5R-6867 | [1] | COUPLER AS-QUICK DISCONNECT(MALE) | |
| 5. | 5R-6868 | [1] | COUPLER AS-QUICK DISCONNECT(FEMALE) | |
| 6. | 102-8705 | [4] | PLATE(TOP) | |
| 7. | 144-0809I | [1] | HOSE AS | |
| 8. | 154-4881 | [8] | CLAMP-HALF | |
| 9. | 179-9117I | [1] | HOSE AS | |
| 10. | 195-6086I | [1] | HOSE AS | |
| 11. | 237-9910I | [1] | HOSE AS | |
| 12. | 237-9919I | [1] | HOSE AS | |
| 13. | 237-9921I | [1] | HOSE AS | |
| 14. | 148-8366 | [2] | ELBOW AS | |
| | | | (EACH INCLUDES) |
| | 6V-8397 | [2] | SEAL-O-RING | |
| | 6V-8987 | [1] | ELBOW | |
| 15. | 150-3070 | [2] | ADAPTER AS | |
| | | | (EACH INCLUDES) |
| | 3J-1907 | [1] | SEAL-O-RING | |
| | 7X-3163 | [1] | ADAPTER-SWIVEL | |
| 16. | 6V-9168 | [2] | NUT(11/16-16-THD) | |
| 17. | 7X-0818M | [3] | BOLT(M8X1.25X45-MM) | |
| 18. | 8T-4224 | [1] | WASHER-HARD(8.8X16X2-MM THK) | |
| 19. | 8T-6912M | [1] | BOLT(M8X1.25X50-MM) | |
| 20. | 154-1420BE | | SLEEVE | |
| | B | | USE AS REQUIRED |
| | E | | ORDER BY THE CENTIMETER |
| | I | | REFER TO HYDRAULIC INFORMATION SYSTEM |
| | M | | METRIC PART |
