卡特零件查询（AP-1055D） 333-7609: PUMP GP-PISTON
广数供应链运营团队, 16 02月, 2025，浏览：
892 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | 232-1528Y | [2] | VALVE GP-SOLENOID(CONVEYOR PUMP) | |
| 2. | 116-3878 | [6] | SCREW(M8X1.25X30-MM) | |
| 3. | 116-3877 | [8] | SCREW | |
| 4. | 164-6665 | [2] | SCREW | |
| 5. | 116-3871 | [4] | NUT-SEAL | |
| 6. | 165-9130 | [2] | SPOOL | |
| 7. | 175-2544 | [2] | SPRING | |
| 8. | 174-6117 | [2] | PLUG | |
| 9. | 3K-0360 | [4] | SEAL-O-RING | |
| 10. | 175-2545 | [2] | ADAPTER-SPRING | |
| 11. | 9S-9334 | [2] | PLUG | |
| 12. | 7M-8485 | [2] | SEAL-O-RING | |
| 13. | 9S-8004 | [2] | PLUG(9/16-18-THD) | |
| 14. | 169-8595 | [2] | PIN | |
| 15. | 077-8353 | [2] | PIN(SPRING) | |
| 16. | 116-1330 | [2] | LINK | |
| 17. | 116-1333 | [2] | SCREW-MOUNTING | |
| 18. | 116-1331 | [2] | LINK-FEEDBACK | |
| 19. | 116-1332 | [2] | LINKAGE-CONTROL | |
| 20. | 219-3301 | [2] | GASKET | |
| 21. | 9S-4191 | [8] | PLUG(9/16-18-THD) | |
| 22. | 3J-1907 | [8] | SEAL-O-RING | |
| 23. | 164-6956 | [4] | GASKET-COVER | |
| 26. | 165-5560 | [20] | SCREW(M6X1X30-MM) | |
| 27. | 6R-1703 | [1] | POPPET | |
| 28. | 1G-5730 | [1] | SPRING | |
| 29. | 161-6565 | [1] | PLUG | |
| 30. | 2M-9780 | [7] | SEAL-O-RING | |
| 31. | 6R-1702 | [1] | NUT-SPECIAL(7/8-14-THD) | |
| 32. | 165-9766 | [1] | PLATE | |
| 35. | 3J-0695 | [2] | BEARING AS-NEEDLE | |
| 36. | 188-2921 | [2] | SWASHPLATE | |
| 37. | 220-0553 | [2] | GASKET | |
| 38. | 132-6697M | [12] | BOLT(M8X1.25X20-MM) | |
| 39. | 220-0555 | [1] | PLATE | |
| 40. | 116-3873 | [1] | RING-RETAINING | |
| 41. | 391-7089 | [1] | CARRIER-SEAL | |
| 42. | 6V-1196 | [1] | SEAL-O-RING | |
| 43. | 4L-6944 | [2] | BEARING AS-NEEDLE | |
| 44. | 220-0551 | [1] | COUPLING | |
| 45. | 217-3617 | [4] | SPRING | |
| 46. | 369-4730 | [4] | VALVE GP-CHECK & RELIEF | |
| 48. | 7X-5453 | [4] | RING-BACKUP | |
| 49. | 6V-5142 | [4] | SEAL-O-RING | |
| 50. | 9S-8006 | [2] | PLUG(7/8-14-THD) | |
| 51. | 222-3043 | [1] | BEARING AS-BALL | |
| 52. | 222-3086 | [1] | RING-RETAINING | |
| 53. | 374-5252 | [1] | COUPLING | |
| 54. | 7X-9372 | [1] | SEAL-O-RING | |
| 55. | 8T-7811M | [2] | BOLT-SOCKET HEAD(M12X1.75X50-MM) | |
| 56. | 129-3180M | [2] | LOCKNUT(M12X1.75-THD) | |
| | | | |
| | | | PARTS SHOWN IN GRAPHIC(S) WITHOUT A REFERENCE NUMBER ARE NOT SERVICED SEPARATELY |
| | | | |
| | | | AVAILABLE REPAIR KIT(S): |
| | 165-9138H | [4] | KIT-PISTON RING | |
| | | | (ALSO INCLUDES PARTS MARKED H IN GRAPHIC) |
| | 165-9137J | [2] | KIT-SERVO PISTON | |
| | | | (ALSO INCLUDES PARTS MARKED J IN GRAPHIC) |
| | 165-9761L | [2] | KIT-PUMP ROTATING GROUP | |
| | | | (ALSO INCLUDES PARTS MARKED L IN GRAPHIC) |
| | 165-9123N | [2] | KIT-BEARING | |
| | | | (ALSO INCLUDES PARTS MARKED N IN GRAPHIC) |
| | 116-2005P | [4] | KIT-VALVE PLUG | |
| | | | (ALSO INCLUDES PARTS MARKED P IN GRAPHIC) |
| | 171-9785T | [1] | KIT-SHAFT | |
| | | | (ALSO INCLUDES PARTS MARKED T IN GRAPHIC) |
| | 232-1566U | [1] | KIT-SEAL | |
| | | | (ALSO INCLUDES PARTS MARKED U IN GRAPHIC) |
| | H | | KIT MARKED H SERVICES PART(S) MARKED H |
| | J | | KIT MARKED J SERVICES PART(S) MARKED J |
| | L | | KIT MARKED L SERVICES PART(S) MARKED L |
| | M | | METRIC PART |
| | N | | KIT MARKED N SERVICES PART(S) MARKED N |
| | P | | KIT MARKED P SERVICES PART(S) MARKED P |
| | T | | KIT MARKED T SERVICES PART(S) MARKED T |
| | U | | KIT MARKED U SERVICES PART(S) MARKED U |
| | Y | | SEPARATE ILLUSTRATION |
