卡特零件查询（AP-1055D） 224-5778: DRIVE GP-CONVEYOR
广数供应链运营团队, 16 02月, 2025，浏览：
500 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | 3R-6274 | [2] | COLLAR | |
| 2. | 103-3599 | [2] | SPROCKET AS(12-TEETH) | |
| 3. | 136-9392 | [2] | KEY-SQUARE | |
| 4. | 155-2937 | [2] | CHAIN AS-ROLLER | |
| | 5B-6377 | [1] | LINK-ROLLER | |
| | 5B-6388 | [1] | LINK-CONNECTING | |
| | 5B-6410 | [1] | LINK-OFFSET | |
| 5. | 341-9467Y | [2] | PLANETARY GP-CONVEYOR | |
| 6. | 230-3451Y | [1] | SHAFT GP-FEEDER DRIVE | |
| 7. | 233-4474 | [2] | PLATE-ADJUSTMENT | |
| 8. | 243-2366 | [2] | PLATE AS | |
| 9. | 152-0191M | [2] | BOLT(M24X3X120-MM) | |
| 10. | 2H-3906 | [4] | SETSCREW-SOCKET(1/2-13X1-IN) | |
| 11. | 7X-2576M | [6] | BOLT(M24X3X70-MM) | |
| 12. | 8L-9811 | [2] | RING-RETAINING | |
| 13. | 8T-4001M | [4] | NUT(M24X3-THD) | |
| 14. | 8T-4139M | [12] | BOLT(M12X1.75X30-MM) | |
| 15. | 8T-4167 | [12] | WASHER-HARD(26X44X4-MM THK) | |
| 16. | 8T-4223 | [28] | WASHER-HARD(13.5X25.5X3-MM THK) | |
| 17. | 8T-4244M | [12] | NUT(M12X1.75-THD) | |
| 18. | 8T-4910M | [12] | BOLT(M12X1.75X60-MM) | |
| 19. | 8T-4956M | [4] | BOLT(M12X1.75X35-MM) | |
| | M | | METRIC PART |
| | Y | | SEPARATE ILLUSTRATION |
