卡特零件查询（AP-1055E） 358-5419: WIRING GP-SCREED
广数供应链运营团队, 16 02月, 2025，浏览：
474 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | 3E-5239 | [1] | RELAY AS(24-VOLT)(SCREED EXTEND, LH) | |
| 1A. | 3E-5239 | [1] | RELAY AS(24-VOLT)(SCREED RETRACT, LH) | |
| 1B. | 3E-5239 | [1] | RELAY AS(24-VOLT)(SCREED EXTEND, LH) | |
| 1C. | 3E-5239 | [1] | RELAY AS(24-VOLT)(SCREED RETRACT, RH) | |
| 2. | 177-2215 | [3] | STRAP-DUAL CLAMP | |
| 3. | 358-5418 | [1] | HARNESS AS-SCREED | |
| | 9X-3401 | [6] | PIN-CONNECTOR(16-GA TO 18-GA) | |
| | 3E-5519 | [4] | PLUG AS-CONNECTOR(5-PIN) | |
| | 155-2270 | [4] | KIT-CONNECTING PLUG(2-PIN) | |
| | | | (EACH INCLUDES PLUG AS, WEDGE & INTERFACE SEAL) |
| | 212-8375 | [4] | PLUG | |
| | 102-8805 | [1] | KIT-RECEPTACLE(6-PIN) | |
| | | | (INCLUDES RECEPTACLE AS & WEDGE) |
| | 180-9340 | [8] | SOCKET-CONNECTOR(14-GA TO 18-GA) | |
| | 9X-1056 | [16] | TERMINAL-RECEPTACLE(14-GA TO 16-GA) | |
| | 125-7875E | | TUBE-HEAT SHRINK(7.44-MM DIA)(20-CM) | |
| 4. | 5C-9553M | [4] | BOLT(M6X1X16-MM) | |
| 5. | 7K-1181 | [1] | STRAP-CABLE | |
| 6. | 9X-8256 | [4] | WASHER(6.6X12X2-MM THK) | |
| | E | | ORDER BY THE CENTIMETER |
| | M | | METRIC PART |
