卡特零件查询（AP-1055E） 354-0854: PUMP & MTG GP-AUXILIARY
广数供应链运营团队, 16 02月, 2025，浏览：
971 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | 366-2485Y | [1] | PUMP GP-GEAR(AUXILIARY) | |
| 2. | 148-8333 | [1] | CONNECTOR AS | |
| | 6V-8400 | [1] | SEAL-O-RING | |
| | 7M-8485 | [1] | SEAL-O-RING | |
| | 8T-7927 | [1] | CONNECTOR | |
| 3. | 148-8387 | [1] | ELBOW AS | |
| | 6V-8400 | [1] | SEAL-O-RING | |
| | 6V-9855 | [1] | ELBOW | |
| 4. | 153-6244 | [1] | ELBOW AS | |
| | 2M-9780 | [1] | SEAL-O-RING | |
| | 6V-9746 | [1] | SEAL-O-RING | |
| | 8T-5389 | [1] | ELBOW | |
| 5. | 304-8018 | [1] | ADAPTER AS | |
| | 3D-2824 | [1] | SEAL-O-RING | |
| | 6V-5258 | [1] | ADAPTER | |
| 6. | 6D-1004 | [1] | GASKET | |
| 7. | 8T-4121 | [2] | WASHER-HARD(11X21X2.5-MM THK) | |
| 8. | 9X-6032M | [2] | BOLT-SOCKET HEAD(M10X1.5X30-MM) | |
| | M | | METRIC PART |
| | Y | | SEPARATE ILLUSTRATION |
