卡特零件查询（AP-1055E） 282-8520: SENSOR GP-SONIC
广数供应链运营团队, 16 02月, 2025，浏览：
952 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | 108-2408 | [1] | SENSOR GP-GRADE(CONTROL) | |
| | 113-1551 | [1] | KIT-FILTER(FOAM) | |
| | | | (INCLUDES FOAMS) |
| | 113-1550 | [1] | KIT-TRANSDUCER | |
| | | | (INCLUDES SCREWS, WRAPS, TRANSDUCER, O-RING SEAL & FOAM KIT) |
| | 285-3251 | [1] | PLATE-RETAINER | |
| 2. | 108-2410 | [1] | BAIL-TEMPERATURE | |
| 3. | 108-2423 | [1] | CABLE AS | |
| | 104-6863 | [1] | CLAMP | |
| | 110-4295 | [1] | PLUG | |
| | 110-4296 | [1] | PLUG | |
| | 110-6863 | [1] | CABLE | |
| | 111-1308 | [2] | BUSHING | |
| | 111-3262 | [2] | NUT(6-32-THD) | |
| | 111-3263 | [2] | NUT(8-32-THD) | |
| | 111-8205 | [1] | BACKSHELL | |
| 4. | 134-9621 | [3] | HANDLE | |
| 5. | 134-9622 | [1] | BRACKET | |
| 6. | 146-9410 | [2] | COLLAR | |
| 7. | 298-0644 | [2] | MOUNT AS-SENSOR | |
| 8. | 264-3631 | [1] | BOLT(3/4-10X2.5-IN) | |
| 9. | 7X-0366 | [2] | BOLT(3/4-10X2-IN) | |
| 10. | 8C-8842 | [1] | BOLT(3/4-10X4-IN) | |
| 11. | 8T-4994 | [1] | WASHER-HARD(20X36.5X3.5-MM THK) | |
