卡特零件查询（BG1055E） 342-7821: LINES GP-FUEL
广数供应链运营团队, 16 02月, 2025，浏览：
862 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | 5E-9313 | [1] | FITTING-HOSE | |
| 2. | 8T-6725 | [1] | CONNECTOR | |
| 3. | 8T-9655 | [6] | MOUNT-ISOLATION | |
| 4. | 149-8142 | [1] | CONNECTOR | |
| 5. | 191-1782 | [3] | SPACER(8.5X12.7X38.2-MM THK) | |
| 6. | 354-0829I | [1] | HOSE | |
| 7. | 361-5097Y | [1] | PUMP GP-FUEL(24-VOLT, ARD) | |
| 8. | 214-7566 | [1] | SEAL-O-RING | |
| 9. | 214-7568 | [1] | SEAL-O-RING | |
| 10. | 228-7089 | [4] | SEAL-O-RING | |
| 11. | 228-7102 | [1] | SEAL-O-RING | |
| 12. | 238-5080 | [4] | SEAL-O-RING | |
| 13. | 337-8788 | [1] | ELBOW | |
| 14. | 5P-4961 | [4] | CLAMP-HOSE | |
| 15. | 6V-8724 | [1] | ELBOW | |
| 16. | 6V-9850 | [1] | ELBOW | |
| 17. | 8T-0119 | [1] | ELBOW | |
| 18. | 8T-6869M | [3] | BOLT(M8X1.25X60-MM) | |
| 19. | 9N-0869 | [6] | WASHER-HARD(8.8X25.5X2-MM THK) | |
| 20. | 9S-4185 | [2] | PLUG(3/4-16-THD) | |
| 21. | 347-8645E | | HOSE(19-CM) | |
| 22. | 347-8646E | | HOSE(31.5-CM) | |
| | E | | ORDER BY THE CENTIMETER |
| | I | | REFER TO HYDRAULIC INFORMATION SYSTEM |
| | M | | METRIC PART |
| | Y | | SEPARATE ILLUSTRATION |
