卡特零件查询（AP-1055F） 394-1235: LINES GP-DIESEL EXHAUST FLUID
广数供应链运营团队, 16 02月, 2025，浏览：
219 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | 9G-5582 | [1] | LOCK AS-CYLINDER | |
| | 226-0294J | [1] | LOCK AS | |
| | 226-0340 | [1] | CAM | |
| 2. | 111-1777 | [1] | BUMPER-RUBBER | |
| 3. | 142-6950 | [1] | HINGE AS | |
| 4. | 344-5675M | [6] | NUT(M10X1.5-THD) | |
| 5. | 389-9441 | [1] | INSULATION | |
| 6. | 398-3011 | [1] | CAP-TANK FILLER(DIESEL EXHAUST FLUID) | |
| 7. | 417-0117 | [1] | BRACKET | |
| 8. | 421-8563 | [1] | HOSE AS | |
| 9. | 507-1532 | [1] | DOOR AS | |
| | 8T-4967M | [2] | STUD-WELD(M10X1.5X23-MM) | |
| 10. | 507-5514 | [3] | SHIM | |
| 11. | 507-5516 | [1] | BRACKET | |
| 12. | 132-5789 | [1] | CLIP(LADDER) | |
| 13. | 387-5467 | [1] | LANYARD | |
| 14. | 6D-4246 | [3] | CLIP(LOOP) | |
| 15. | 7K-1181 | [1] | STRAP-CABLE | |
| 16. | 7X-7729 | [2] | WASHER(11X25X3-MM THK) | |
| 17. | 8T-4121 | [7] | WASHER-HARD(11X21X2.5-MM THK) | |
| 18. | 8T-4133M | [1] | NUT(M10X1.5-THD) | |
| 19. | 8T-4137M | [2] | BOLT(M10X1.5X20-MM) | |
| 20. | 9X-2041M | [2] | SCREW-TRUSS HEAD(M10X1.5X20-MM) | |
| | J | | REQUIRES CORPORATE KEY |
| | M | | METRIC PART |
