卡特零件查询（AP-1055F） 392-4705: LINES GP-GRADE & SLOPE
广数供应链运营团队, 16 02月, 2025，浏览：
620 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | 102-8703 | [1] | PLATE-COVER | |
| 2. | 102-8705 | [1] | PLATE(TOP) | |
| 3. | 213-2265 | [2] | UNION AS | |
| | | | (EACH INCLUDES) |
| | 6V-8397 | [2] | SEAL-O-RING | |
| | 150-0128 | [1] | UNION | |
| 4. | 346-5084I | [1] | HOSE AS | |
| 5. | 359-5199I | [1] | HOSE AS | |
| 6. | 384-9505I | [1] | HOSE AS | |
| 7. | 394-2530I | [1] | HOSE AS | |
| 8. | 423-3187I | [1] | HOSE AS | |
| 9. | 423-8488I | [1] | HOSE AS | |
| 10. | 423-3191I | [1] | HOSE AS | |
| 11. | 423-8490I | [1] | HOSE AS | |
| 12. | 423-8491I | [1] | HOSE AS | |
| 13. | 423-8492 | [1] | TUBE AS | |
| 14. | 460-9676 | [1] | TUBE AS | |
| 15. | 428-7089I | [1] | HOSE AS | |
| 16. | 142-4443 | [1] | CLIP | |
| 17. | 153-6246 | [2] | TEE AS | |
| | | | (EACH INCLUDES) |
| | 6V-8397 | [3] | SEAL-O-RING | |
| | 7X-0820 | [1] | TEE | |
| 18. | 4V-0611 | [2] | CLAMP | |
| 19. | 177-2215 | [1] | STRAP-DUAL CLAMP | |
| 20. | 200-6345 | [2] | SADDLE-MOUNTING(DUAL SWIVEL) | |
| 21. | 204-2281 | [4] | STRAP-CABLE | |
| 22. | 206-6409 | [2] | CLAMP-HALF | |
| 23. | 327-0325 | [1] | STRAP-CABLE | |
| 24. | 6V-9168 | [4] | NUT(11/16-16-THD) | |
| 25. | 7X-0818M | [1] | BOLT(M8X1.25X45-MM) | |
| 26. | 7X-2537M | [1] | BOLT(M8X1.25X35-MM) | |
| | I | | REFER TO HYDRAULIC INFORMATION SYSTEM |
| | M | | METRIC PART |
