| Pos. | Part No | Qty | Parts name | Comments |
|---|---|---|---|---|
| 1. | 6E-6527 | [1] | PLUG | |
| 2. | 6E-6528 | [1] | SEAL | |
| 3. | 6E-3272 | [1] | SEAT | |
| 4. | 269-4669 | [1] | SOLENOID AS | |
| 217-3875 | [1] | SEAL-O-RING | ||
| 5. | 213-9242 | [1] | SEAL-O-RING | |
| 6. | 213-9247 | [1] | SEAL-O-RING | |
| 7. | 209-6004 | [1] | RING | |
| 8. | 8T-8442M | [4] | BOLT-SOCKET HEAD(M6X1X30-MM) | |
| 9. | 213-9803 | [1] | PLUG-ORIFICE | |
| 10. | 9X-7680 | [1] | SEAL-O-RING | |
| 11. | 280-7870 | [1] | GASKET | |
| 12. | 6E-6419 | [1] | RING | |
| 13. | 100-5738M | [1] | NUT(M6X0.5-THD) | |
| M | METRIC PART | |||
