卡特零件查询（AP-1055F） 390-4822: FRAME GP-SCREED
广数供应链运营团队, 16 02月, 2025，浏览：
451 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | 394-5226 | [1] | FRAME AS | |
| 2. | 394-5229 | [1] | FRAME AS | |
| 3. | 394-5232 | [1] | FRAME AS | |
| 4. | 398-0617 | [1] | FRAME AS | |
| 5. | 398-0630 | [2] | TUBE AS | |
| 6. | 464-0480 | [2] | TUBE AS | |
| 7. | 422-4637M | [24] | NUT(M30X2-THD) | |
| 8. | 422-4810 | [1] | FRAME AS(LH) | |
| 9. | 422-4812 | [1] | FRAME AS(RH) | |
| 10. | 422-9029B | [2] | SHIM(3-MM THK) | |
| 11. | 422-9030B | [2] | SHIM(1.6-MM THK) | |
| 12. | 440-9436B | [2] | SHIM(1.6-MM THK) | |
| 13. | 440-9437B | [2] | SHIM(3-MM THK) | |
| 14. | 457-5146B | [2] | SHIM(0.8-MM THK) | |
| 15. | 457-5245B | [2] | SHIM(0.8-MM THK) | |
| 16. | 7X-2577M | [16] | BOLT(M24X3X90-MM) | |
| 17. | 8T-4123 | [16] | WASHER(22X35X3.5-MM THK) | |
| 18. | 8T-4167 | [16] | WASHER-HARD(26X44X4-MM THK) | |
| 19. | 8T-4187M | [16] | BOLT(M20X2.5X80-MM) | |
| | B | | USE AS REQUIRED |
| | M | | METRIC PART |
