卡特零件查询（BG-225C） 3T-4352: ROLLER GP-TRACK
广数供应链运营团队, 16 02月, 2025，浏览：
327 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | 0S-1585 | [4] | BOLT(1/2-13X1.5-IN) | |
| | 2M-0849 | [4] | WASHER-HARD(13.5X25.5X5-MM THK) | |
| 2. | 7D-9749 | [2] | SEAL-O-RING | |
| 3. | 6S-3172 | [2] | RING | |
| 4. | 9F-2247 | [1] | PLUG-PIPE | |
| 5. | 6S-7038C | [1] | RIM AS | |
| 6. | 6S-3495 | [2] | BEARING AS | |
| | | | (EACH INCLUDES) |
| | 6S-8233 | [1] | BEARING | |
| 7. | 6S-3171 | [1] | SHAFT | |
| 8. | 3T-4283 | [2] | COLLAR | |
| 9. | 6S-7715 | [2] | WASHER-THRUST(52X86X6.35-MM THK) | |
| 10. | 6S-3285 | [2] | SEAL GP-DUO-CONE | |
| | | | (EACH INCLUDES) |
| | 6S-3284 | [2] | RING-TORIC | |
| | | | -OR- |
| | 5P-0373A | [2] | SEAL GP | |
| | | | (EACH INCLUDES) |
| | 3N-3095 | [2] | RING-SEALING | |
| | | | (FOR EXTREME TEMPERATURES) |
| | A | | NOT PART OF THIS GROUP |
| | C | | CHANGE FROM PREVIOUS TYPE |
| | R | | REMANUFACTURED PART MAY BE AVAILABLE |
