卡特零件查询（BG-225C） 150-7725: EXTENSION AR-SCREED
广数供应链运营团队, 16 02月, 2025，浏览：
1003 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| | 106-9688Y | [2] | BEARING GP-AUGER | |
| | 106-9689Y | [2] | BRACE GP | |
| | 106-3483Y | [2] | EXTENSION AR(DIESEL HEAT, 28-IN) | |
| | 5E-9808Y | [1] | EXTENSION GP-AUGER(1-FT, LH) | |
| | 5E-9809Y | [1] | EXTENSION GP-AUGER(1-FT, RH) | |
| | 5E-9825Y | [1] | EXTENSION GP-AUGER(2-FT, LH) | |
| | 5E-9826Y | [1] | EXTENSION GP-AUGER(2-FT, RH) | |
| | 106-9715Y | [2] | EXTENSION GP-MAIN FRAME(2-FT) | |
| | 116-2470Y | [1] | EXTENSION GP-MAIN FRAME | |
| | 109-2722Y | [2] | BRACKET GP-SUPPORT | |
| | Y | | SEPARATE ILLUSTRATION |
