卡特零件查询（AP-655C） 198-6172: LINES GP-PAVER VENTILATION
广数供应链运营团队, 16 02月, 2025，浏览：
693 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | 120-4543I | [1] | HOSE AS | |
| 2. | 166-5921I | [1] | HOSE AS | |
| 3. | 148-8374 | [1] | ELBOW AS | |
| | 3K-0360 | [1] | SEAL-O-RING | |
| | 6V-8397 | [1] | SEAL-O-RING | |
| | 6V-8723 | [1] | ELBOW | |
| 4. | 164-9869 | [1] | CONNECTOR AS | |
| | 3J-1907 | [1] | SEAL-O-RING | |
| | 6V-8397 | [1] | SEAL-O-RING | |
| | 9X-2297 | [1] | CONNECTOR | |
| 5. | 8M-2773 | [3] | CLIP(LOOP) | |
| 6. | 8T-4224 | [2] | WASHER-HARD(8.8X16X2-MM THK) | |
| 7. | 8T-6912M | [2] | BOLT(M8X1.25X50-MM) | |
| | I | | REFER TO HYDRAULIC INFORMATION SYSTEM |
| | M | | METRIC PART |
