卡特零件查询（AP-655C） 198-6171: LINES GP-TRUCK HITCH
广数供应链运营团队, 16 02月, 2025，浏览：
874 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | 154-4890M | [2] | BOLT-STACKING(M8X1.25X33-MM) | |
| 2. | 119-4314I | [1] | HOSE AS | |
| 3. | 102-8703 | [2] | PLATE-COVER | |
| 4. | 130-7218 | [2] | TUBE AS | |
| 5. | 149-3355I | [2] | HOSE AS | |
| 6. | 154-2854I | [1] | HOSE AS | |
| 7. | 162-1414I | [2] | HOSE AS | |
| 8. | 206-0452 | [2] | PLATE | |
| 9. | 206-6409 | [8] | CLAMP-HALF | |
| 10. | 223-5557 | [1] | TUBE AS | |
| 11. | 223-5558 | [1] | TUBE AS | |
| 12. | | [2] | ELBOW AS |
| | | | (EACH INCLUDES) |
| | 6V-8397 | [1] | SEAL-O-RING | |
| | 9X-2195 | [1] | ELBOW | |
| 13. | 148-8318 | [1] | CONNECTOR AS | |
| | 3K-0360 | [1] | SEAL-O-RING | |
| | 6V-8397 | [1] | SEAL-O-RING | |
| | 6V-8634 | [1] | CONNECTOR | |
| 14. | 148-8374 | [1] | ELBOW AS | |
| | 3K-0360 | [1] | SEAL-O-RING | |
| | 6V-8397 | [1] | SEAL-O-RING | |
| | 6V-8723 | [1] | ELBOW | |
| 16. | 6V-8397 | [2] | SEAL-O-RING | |
| 17. | 6V-9168 | [2] | NUT(11/16-16-THD) | |
| 18. | 6V-9829B | [2] | CAP(ORFS) | |
| 19. | 7X-2537M | [2] | BOLT(M8X1.25X35-MM) | |
| 20. | 154-1420E | | SLEEVE(43-CM EACH) | |
| 21. | 3S-2093 | [4] | STRAP-CABLE | |
| | B | | USE AS REQUIRED |
| | E | | ORDER BY THE CENTIMETER |
| | I | | REFER TO HYDRAULIC INFORMATION SYSTEM |
| | M | | METRIC PART |
