| Pos. | Part No | Qty | Parts name | Comments |
|---|---|---|---|---|
| 1. | 9X-1439Y | [4] | LAMP GP-FLOOD(24-VOLT) | |
| 2. | 200-0238 | [2] | BRACKET | |
| 3. | 5D-7635 | [4] | GROMMET | |
| 4. | 8T-4121 | [12] | WASHER-HARD(11X21X2.5-MM THK) | |
| 5. | 8T-4133M | [6] | NUT(M10X1.5-THD) | |
| 6. | 8T-4195M | [4] | BOLT(M10X1.5X30-MM) | |
| 7. | 8T-4196M | [4] | BOLT(M10X1.5X35-MM) | |
| M | METRIC PART | |||
| Y | SEPARATE ILLUSTRATION | |||
