卡特零件查询（AP-655C） 199-4253: DOOR GP-ACCESS
广数供应链运营团队, 16 02月, 2025，浏览：
623 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | 3B-4617 | [4] | PIN-COTTER | |
| 2. | 7R-3336 | [4] | PIN | |
| 3. | 108-7756 | [3] | ROD(PROP) | |
| 4. | 111-1777 | [11] | BUMPER-RUBBER | |
| 5. | 141-9203M | [39] | SCREW-BUTTON HEAD(M10X1.5X30-MM) | |
| 6. | 142-3041B | [3] | SHIM(6-MM THK) | |
| 7. | 142-5057B | [3] | SHIM(2-MM THK) | |
| 8. | 152-1061 | [3] | BAR | |
| 9. | 177-1570 | [3] | LATCH AS | |
| | | | (EACH INCLUDES) |
| | 217-0733 | [1] | LOCK AS | |
| 10. | 193-9297 | [1] | PLATE(BENT) | |
| 11. | 198-3133 | [1] | HINGE | |
| 12. | | [2] | HINGE |
| 13. | 198-5159 | [4] | PLATE | |
| 14. | 198-5466 | [1] | COVER AS | |
| | 7X-2484 | [1] | LATCH-HANDLE | |
| 15. | 199-4218 | [2] | HINGE | |
| 16. | 199-4219 | [1] | HINGE | |
| 17. | 199-4220 | [2] | BRACKET | |
| 18. | 199-4226 | [2] | BRACKET | |
| 19. | 199-4236 | [1] | DOOR AS | |
| 20. | 199-4347 | [1] | RAIL AS | |
| 21. | 199-4348 | [1] | RAIL AS | |
| 22. | 199-7509 | [1] | PLATE | |
| 23. | 199-7511 | [1] | PLATE | |
| 24. | 199-7514 | [1] | RAIL AS | |
| 25. | 199-7521 | [1] | DOOR AS | |
| 26. | 204-5700 | [1] | COVER | |
| 27. | 207-1725 | [1] | DOOR AS(LH) | |
| | 7T-1099 | [2] | LINK | |
| | 7X-2484 | [1] | LATCH-HANDLE | |
| 28. | 207-1726 | [1] | DOOR AS(RH) | |
| | 7X-2484 | [1] | LATCH-HANDLE | |
| 29. | 207-1733 | [1] | COVER AS(LH) | |
| 30. | 208-4729 | [2] | HINGE | |
| 31. | 208-6185 | [1] | PLATE(BENT) | |
| 32. | 208-6188 | [1] | PLATE(BENT)(ASSEMBLE TO CENTER PLATE) | |
| 33. | 208-6190 | [2] | PLATE | |
| 34. | 215-6604 | [2] | HINGE | |
| 35. | 215-6605 | [2] | HINGE | |
| 36. | 215-6607 | [1] | PLATE AS | |
| 37. | 215-6608 | [1] | PLATE | |
| 38. | 215-6609 | [1] | PLATE AS | |
| 39. | 215-6612 | [1] | PLATE AS | |
| 40. | 218-7290 | [1] | PLATE | |
| 41. | 218-7317 | [1] | PLATE AS | |
| 42. | 218-7319 | [1] | PLATE AS | |
| 43. | 218-7325 | [1] | RAIL AS | |
| 44. | 238-9819 | [1] | DOOR AS | |
| 45. | 222-2368 | [1] | BRACKET | |
| 46. | 251-3257 | [1] | PLATE AS | |
| 47. | 222-5151 | [3] | PAWL | |
| 48. | 223-2536 | [1] | PLATE AS | |
| 49. | 224-2103 | [1] | PLATE AS | |
| 50. | 229-5008 | [1] | SHEET-RUBBER | |
| 51. | 3B-4618 | [3] | PIN-COTTER | |
| 52. | 4I-3124M | [6] | BOLT(M8X1.25X32-MM) | |
| 53. | 5C-7261M | [4] | NUT(M8X1.25-THD) | |
| 54. | 5P-4116 | [6] | WASHER-HARD(8.8X20.5X2-MM THK) | |
| 55. | 8C-8585M | [20] | SCREW-BUTTON HEAD(M10X1.5X20-MM) | |
| 56. | 8T-3991M | [3] | SCREW-BUTTON HEAD(M6X1X20-MM) | |
| 57. | 8T-4121 | [154] | WASHER-HARD(11X21X2.5-MM THK) | |
| 58. | 8T-4133M | [93] | NUT(M10X1.5-THD) | |
| 59. | 8T-4136M | [29] | BOLT(M10X1.5X25-MM) | |
| 60. | 8T-4137M | [19] | BOLT(M10X1.5X20-MM) | |
| 61. | 8T-4183M | [1] | BOLT(M12X1.75X40-MM) | |
| 62. | 8T-4184M | [2] | BOLT(M12X1.75X45-MM) | |
| 63. | 8T-4186M | [1] | BOLT(M10X1.5X40-MM) | |
| 64. | 8T-4189M | [4] | BOLT(M8X1.25X20-MM) | |
| 65. | 8T-4195M | [7] | BOLT(M10X1.5X30-MM) | |
| 66. | 8T-4196M | [5] | BOLT(M10X1.5X35-MM) | |
| 67. | 8T-4223 | [7] | WASHER-HARD(13.5X25.5X3-MM THK) | |
| 68. | 8T-4224 | [12] | WASHER-HARD(8.8X16X2-MM THK) | |
| 69. | 8T-4244M | [4] | NUT(M12X1.75-THD) | |
| 70. | 8T-6868M | [1] | BOLT(M12X1.75X80-MM) | |
| 71. | 8T-7547M | [2] | BOLT(M8X1.25X30-MM) | |
| 72. | 5P-8309BE | | SEAL | |
| | B | | USE AS REQUIRED |
| | E | | ORDER BY THE CENTIMETER |
| | M | | METRIC PART |
