卡特零件查询（AP-655C） 192-9376: DRIVE GP-CONVEYOR
广数供应链运营团队, 16 02月, 2025，浏览：
910 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | 2H-3906 | [4] | SETSCREW-SOCKET(1/2-13X1-IN) | |
| 2. | 3R-6274 | [2] | COLLAR | |
| 3. | 103-3599 | [2] | SPROCKET AS(12-TEETH) | |
| 4. | 136-9392 | [2] | KEY-SQUARE | |
| 5. | 192-7962Y | [2] | PLANETARY GP-CONVEYOR | |
| 6. | 192-9175 | [1] | PLATE AS | |
| | 6V-7742M | [2] | NUT-FULL(M20X2.5-THD) | |
| 7. | 193-1077Y | [1] | SHAFT GP-FEEDER DRIVE | |
| 8. | 194-0884 | [2] | CHAIN-ROLLER | |
| | | | (EACH INCLUDES) |
| | 5B-6377 | [1] | LINK-ROLLER | |
| | 5B-6388 | [1] | LINK-CONNECTING | |
| 9. | 198-6088 | [1] | PLATE AS | |
| | 6V-7742M | [2] | NUT-FULL(M20X2.5-THD) | |
| 10. | 198-6089 | [2] | GUARD | |
| 11. | 5P-4115 | [4] | WASHER-HARD(7.2X19X2-MM THK) | |
| 12. | 7X-2565M | [4] | BOLT(M20X2.5X100-MM) | |
| 13. | 8L-9811 | [2] | RING-RETAINING | |
| 14. | 8T-4123 | [4] | WASHER(3.62X5.75X0.375-MM THK) | |
| 15. | 8T-4138M | [4] | BOLT(M6X1X20-MM) | |
| 16. | 8T-4139M | [16] | BOLT(M12X1.75X30-MM) | |
| 17. | 8T-4194M | [12] | BOLT(M12X1.75X50-MM) | |
| 18. | 8T-4223 | [28] | WASHER-HARD(13.5X25.5X3-MM THK) | |
| 19. | 8T-4244M | [12] | NUT(M12X1.75-THD) | |
| 20. | 8T-6430M | [8] | BOLT(M20X2.5X50-MM) | |
| 21. | 8T-5439 | [8] | WASHER-HARD(21.5X45X6-MM THK) | |
| | M | | METRIC PART |
| | Y | | SEPARATE ILLUSTRATION |
