| Pos. | Part No | Qty | Parts name | Comments |
|---|---|---|---|---|
| 1. | 147-6260 | [1] | PLATE | |
| 2. | 207-8234 | [1] | PLATE-COVER | |
| 3. | 148-8407 | [1] | PLUG AS | |
| 3J-1907 | [1] | SEAL-O-RING | ||
| 9S-4191 | [1] | PLUG(9/16-18-THD) | ||
| 4. | 148-8411 | [1] | PLUG AS | |
| 3K-0360 | [1] | SEAL-O-RING | ||
| 9S-4185 | [1] | PLUG(3/4-16-THD) | ||
| 5. | 8T-4121 | [8] | WASHER-HARD(11X21X2.5-MM THK) | |
| 6. | 8T-4133M | [2] | NUT(M10X1.5-THD) | |
| 7. | 8T-4137M | [4] | BOLT(M10X1.5X20-MM) | |
| M | METRIC PART | |||
