| Pos. | Part No | Qty | Parts name | Comments |
|---|---|---|---|---|
| 1. | 112-0895 | [1] | ROLLER AS | |
| 2. | 166-7817 | [2] | ROLLER | |
| 3. | 102-6664 | [2] | SHAFT AS | |
| 4. | 6I-9487 | [4] | BALL BEARING | |
| 5. | 8I-0625B | [4] | WASHER(38.9X81X4.8-MM THK) | |
| 6. | 8I-0626B | [4] | WASHER(1.53X2.38X.25-IN THK) | |
| 7. | 7X-0396 | [2] | BOLT(7/8-9X8.5-IN) | |
| 8. | 8T-4122 | [2] | WASHER-HARD(17X32X3.5-MM THK) | |
| 9. | 7X-0448 | [2] | NUT(5/8-11-THD) | |
| 10. | 092-2555B | [8] | WASHER(39X72X1.5-MM THK) | |
| B | USE AS REQUIRED | |||
