| 1. | 272-8437 | [1] | PANEL-OPERATOR | |
| 2. | 417-4687Y | [1] | HARNESS AS-PANEL | |
| 3. | 265-9984 | [11] | BRACKET | |
| 4. | 132-3090Y | [1] | LEVER GP-PROPEL | |
| 5. | 246-8912Y | [1] | SWITCH GP-TOGGLE(APRON FOLD) | |
| 5A. | 246-8912Y | [1] | SWITCH GP-TOGGLE(HOPPER, RH) | |
| 5B. | 246-8912Y | [1] | SWITCH GP-TOGGLE(HOPPER, LH) | |
| 5C. | 246-8912Y | [1] | SWITCH GP-TOGGLE(EXTENDER, LH) | |
| 5D. | 246-8912Y | [1] | SWITCH GP-TOGGLE(EXTENDER, RH) | |
| 6. | 8C-9812 | [1] | SWITCH AS-TOGGLE(CONVEYOR, LH) | |
| 6A. | 8C-9812 | [1] | SWITCH AS-TOGGLE(CONVEYOR, RH) | |
| 6B. | 8C-9812 | [1] | SWITCH AS-TOGGLE(AUGER, LH) | |
| 6C. | 8C-9812 | [1] | SWITCH AS-TOGGLE(AUGER, RH) | |
| 7. | 9G-0011 | [1] | SWITCH AS-TOGGLE(TOW POINT CONTROL, LH) | |
| 7A. | 9G-0011 | [1] | SWITCH AS-TOGGLE(TOW POINT CONTROL, RH) | |
| 7B. | 9G-0011 | [1] | SWITCH AS-TOGGLE(AUGER LIFT) | |
| 7C. | 9G-0011 | [1] | SWITCH AS-TOGGLE(AUGER REVERSE) | |
| 7D. | 9G-0011 | [1] | SWITCH AS-TOGGLE(THROTTLE) | |
| | | | (EACH SWITCH AS INCLUDES) |
| | 3L-8187 | [3] | LOCKWASHER | |
| | 6T-3631 | [2] | NUT-HEX(15/32-32-THD) | |
| | 6T-3632 | [1] | LOCKWASHER | |
| | 6T-3633 | [1] | RING-LOCKING | |
| | 6V-8374 | [3] | SCREW-MACHINE(6-32X0.25-IN) | |
| 8. | 9D-3721 | [1] | SWITCH-TOGGLE(SINGLE POLE)(CLEAR) | |
| 9. | 213-8147 | [1] | POTENTIOMETER AS(PROPEL SPEED) | |
| 9A. | 213-8147 | [1] | POTENTIOMETER AS(CONVEYOR SPEED, LH) | |
| 9B. | 213-8147 | [1] | POTENTIOMETER AS(CONVEYOR SPEED, RH) | |
| | 8T-8729 | [1] | PIN-CONNECTOR(16-GA TO 18-GA) | |
| | 102-8803 | [1] | KIT-RECEPTACLE(3-PIN) | |
| | | | (INCLUDES RECEPTACLE AS & WEDGE) |
| | 9X-1813E | | SLEEVE(25-CM) | |
| | E | | TUBE-HEAT SHRINK(4.8-MM DIA)(10-CM) |
| 10. | 1V-6652 | [1] | SWITCH AS-TOGGLE(TURN SIGNAL) | |
| 10A. | 1V-6652 | [1] | SWITCH AS-TOGGLE(TAMPER CONTROL) | |
| 10B. | 1V-6652 | [1] | SWITCH AS-TOGGLE(TRANSMISSION) | |
| | | | (EACH INCLUDES) |
| | 3L-8187 | [3] | LOCKWASHER | |
| | 6T-3631 | [2] | NUT-HEX(15/32-32-THD) | |
| | 6T-3632 | [1] | LOCKWASHER | |
| | 6T-3633 | [1] | RING-LOCKING | |
| | 6V-8374 | [3] | SCREW-MACHINE(6-32X0.25-IN) | |
| 11. | 4D-1836 | [1] | SWITCH-TOGGLE(GENERATOR) | |
| 11A. | 4D-1836 | [1] | SWITCH-TOGGLE(VIBRATORY CONTROL) | |
| 11B. | 4D-1836 | [1] | SWITCH-TOGGLE(COUNTERBALANCE) | |
| 11C. | 4D-1836 | [1] | SWITCH-TOGGLE(SCREED) | |
| 12. | 109-7187 | [1] | SWITCH AS-TOGGLE(SCREED CONTROL) | |
| | 3L-8187 | [3] | LOCKWASHER | |
| | 6T-3631 | [2] | NUT-HEX(15/32-32-THD) | |
| | 6T-3632 | [1] | LOCKWASHER | |
| | 6T-3633 | [1] | RING-LOCKING | |
| | 6V-8374 | [3] | SCREW-MACHINE(6-32X0.25-IN) | |
| 13. | 116-5275 | [1] | SWITCH GP-PUSH BUTTON(OPERATOR)(ENGINE STOP) | |
| 14. | 116-6565 | [1] | BLOCK AS(LIGHT) | |
| | 8L-9801 | [1] | LAMP(12-VOLT) | |
| 15. | 116-5277 | [2] | BLOCK(CONTACT) | |
| 16. | 116-5270 | [1] | LAMP(24-VOLT) | |
| 17. | 347-8607 | [1] | KNOB(PARKING BRAKE) | |
| 18. | 281-4678 | [1] | SWITCH AS-PUSH BUTTON(HAZARD) | |
| 19. | 316-6409 | [3] | LAMP AS(LED)(CONSOLE) | |
| | | | (EACH INCLUDES) |
| | 5P-5694 | [2] | TERMINAL-BLADE(14-GA TO 16-GA) | |
| | 6V-8367 | [1] | LOCKWASHER | |
| | 6V-8382 | [1] | NUT-HEX(11/16-27-THD) | |
| 20. | 3D-9718 | [1] | SWITCH AS-PUSH BUTTON(HORN) | |
| | 6V-8376 | [2] | SCREW-MACHINE(8-32X0.25-IN) | |
| | 6V-8832 | [1] | NUT(5/8-32-THD) | |
| | 9B-7233 | [2] | LOCKWASHER | |
| 21. | 7N-5876 | [4] | LAMP(24-VOLT, 0.2-AMPERE) | |
| 22. | 9D-3127 | [1] | BASE AS-INDICATOR LIGHT | |
| | 6V-8367 | [1] | LOCKWASHER | |
| | 6V-8382 | [1] | NUT-HEX(11/16-27-THD) | |
| 23. | 9D-2868 | [1] | LENS-RED | |
| 24. | 175-3950 | [1] | SWITCH AS-ROTARY(WORK LIGHTS) | |
| | 9W-0852 | [7] | PIN-CONNECTOR(14-GA TO 16-GA) | |
| | 102-8806 | [1] | KIT-RECEPTACLE(8-PIN) | |
| | | | (INCLUDES RECEPTACLE AS & WEDGE) |
| 25. | 7N-8008Y | [1] | SWITCH AS-TOGGLE(LIMP HOME, RH) | |
| 25A. | 7N-8008Y | [1] | SWITCH AS-TOGGLE(LIMP HOME, LH) | |
| 26. | 172-9200 | [2] | SUPPRESSOR-ARC | |
| 27. | 7C-4550 | [3] | SEAL(ROTATING SHAFT) | |
| 28. | 316-5717 | [4] | KNOB AS | |
| 29. | 348-0379 | [1] | FILM-PANEL | |
| 30. | 222-7890 | [1] | SWITCH AS-ROCKER(PARKING BRAKE) | |
| 31. | 393-7092 | [1] | PLUG | |
| 32. | 3V-4694 | [1] | PLUG-BUTTON | |
| | E | | ORDER BY THE CENTIMETER |
| | Y | | SEPARATE ILLUSTRATION |
