| Pos. | Part No | Qty | Parts name | Comments |
|---|---|---|---|---|
| 1. | 155-3504 | [2] | ELBOW AS | |
| (EACH INCLUDES) | ||||
| 2M-9780 | [1] | SEAL-O-RING | ||
| 6V-9003 | [1] | ELBOW | ||
| 7J-9108 | [1] | SEAL-O-RING | ||
| 2. | 499-7348Y | [2] | MOTOR GP-PISTON | |
| 3. | 148-8336 | [2] | CONNECTOR AS | |
| (EACH INCLUDES) | ||||
| 3J-1907 | [1] | SEAL-O-RING | ||
| 6V-8397 | [1] | SEAL-O-RING | ||
| 6V-8636 | [1] | CONNECTOR | ||
| 4. | 192-5168 | [2] | SEAL-O-RING | |
| 5. | 8T-4123 | [4] | WASHER(22X35X3.5-MM THK) | |
| 6. | 8T-6430M | [4] | BOLT(M20X2.5X50-MM) | |
| M | METRIC PART | |||
| Y | SEPARATE ILLUSTRATION | |||
