卡特零件查询（AP555F） 447-9856: VALVE & MTG GP-FLOW CONTROL
广数供应链运营团队, 17 02月, 2025，浏览：
803 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | 433-6599Y | [1] | VALVE GP-FLOW CONTROL(PAVER VENTILATION MOTOR) | |
| 2. | 148-8353 | [1] | ELBOW AS | |
| | 3J-1907 | [1] | SEAL-O-RING | |
| | 6V-8397 | [1] | SEAL-O-RING | |
| | 6V-9001 | [1] | ELBOW | |
| 3. | 148-8378 | [1] | ELBOW AS | |
| | 3J-1907 | [1] | SEAL-O-RING | |
| | 6V-8397 | [1] | SEAL-O-RING | |
| | 6V-8724 | [1] | ELBOW | |
| 4. | 150-4043 | [1] | CONNECTOR AS | |
| | 3J-1907 | [1] | SEAL-O-RING | |
| | 6V-8398 | [1] | SEAL-O-RING | |
| | 6V-9873 | [1] | CONNECTOR | |
| 5. | 6V-8213M | [2] | BOLT-SOCKET HEAD(M8X1.25X70-MM) | |
| | M | | METRIC PART |
| | Y | | SEPARATE ILLUSTRATION |
