卡特零件查询（AP600F） 490-2550: SHOE GP-CUTOFF
广数供应链运营团队, 17 02月, 2025，浏览：
297 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | 490-2543 | [2] | MOUNT AS | |
| 2. | 490-2544 | [2] | MOUNT AS | |
| 3. | 490-2545 | [2] | LINK AS | |
| 4. | 490-2546 | [4] | SHACKLE | |
| 5. | 490-2547 | [2] | CHAIN | |
| 6. | 490-2551 | [1] | SHOE AS-CUTOFF | |
| 7. | 490-2552 | [1] | SHOE AS-CUTOFF | |
| 8. | 490-2558 | [1] | PLATE | |
| 9. | 490-2559 | [1] | PLATE | |
| 10. | 329-3356M | [4] | NUT(M12X1.75-THD) | |
| 11. | 6V-7687M | [2] | LOCKNUT(M12X1.75-THD) | |
| 12. | 7X-0515 | [4] | WASHER-HARD(17X35X5-MM THK) | |
| 13. | 7X-7729 | [8] | WASHER(11X25X3-MM THK) | |
| 14. | 8T-4132M | [2] | NUT(M16X2-THD) | |
| 15. | 8T-4183M | [2] | BOLT(M12X1.75X40-MM) | |
| 16. | 8T-4184M | [4] | BOLT(M12X1.75X45-MM) | |
| 17. | 8T-4193M | [2] | BOLT(M16X2X50-MM) | |
| 18. | 8T-4195M | [8] | BOLT(M10X1.5X30-MM) | |
| 19. | 8T-4223 | [12] | WASHER-HARD(13.5X25.5X3-MM THK) | |
| | M | | METRIC PART |
