卡特零件查询（AP600F） 433-6583: LINES GP-STEERING
广数供应链运营团队, 17 02月, 2025，浏览：
686 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | 7V-5628 | [1] | PLATE(TOP) | |
| 2. | 363-8388I | [1] | HOSE AS | |
| 3. | 363-8389I | [1] | HOSE AS | |
| 4. | 363-8390I | [1] | HOSE AS | |
| 5. | 423-3190 | [2] | PLATE | |
| 6. | 148-8340 | [1] | CONNECTOR AS | |
| | 3K-0360 | [1] | SEAL-O-RING | |
| | 6V-8398 | [1] | SEAL-O-RING | |
| | 6V-8639 | [1] | CONNECTOR | |
| 7. | 177-2215 | [2] | STRAP-DUAL CLAMP | |
| 8. | 200-6345 | [1] | SADDLE-MOUNTING(DUAL SWIVEL) | |
| 9. | 204-2281 | [2] | STRAP-CABLE | |
| 10. | 7V-5626 | [2] | CLAMP | |
| 11. | 8C-8451M | [2] | BOLT(M6X1X40-MM) | |
| 12. | 8T-4189M | [4] | BOLT(M8X1.25X20-MM) | |
| 13. | 8T-4205 | [1] | WASHER-HARD(7.2X14.5X2-MM THK) | |
| 14. | 8T-4224 | [4] | WASHER-HARD(8.8X16X2-MM THK) | |
| 15. | 8T-4971M | [1] | BOLT(M6X1X30-MM) | |
| | I | | REFER TO HYDRAULIC INFORMATION SYSTEM |
| | M | | METRIC PART |
