卡特零件查询（AP655F） 394-1237: MOUNTING GP-ENGINE FLEXIBLE
广数供应链运营团队, 17 02月, 2025，浏览：
569 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | 155-9412 | [2] | MOUNT AS | |
| 2. | 7X-2465M | [2] | BOLT(M24X3X180-MM) | |
| 3. | 8T-4001M | [2] | NUT(M24X3-THD) | |
| 4. | 8T-4123 | [4] | WASHER(22X35X3.5-MM THK) | |
| 5. | 8T-4131M | [2] | NUT(M20X2.5-THD) | |
| 6. | 8T-4167 | [4] | WASHER-HARD(26X44X4-MM THK) | |
| 7. | 8T-4170M | [2] | BOLT(M20X2.5X150-MM) | |
| 8. | 8Y-7119 | [2] | WASHER(26X144X12-MM THK) | |
| 9. | 9W-6582 | [2] | SLEEVE | |
| 10. | 9W-6584 | [2] | WASHER(20.5X114X10-MM THK) | |
| 11. | 9W-7385 | [2] | SLEEVE | |
| 12. | 9W-9930 | [2] | MOUNT AS | |
| | M | | METRIC PART |
