卡特零件查询（BG655D） 270-3544: LINES GP-PUMP
广数供应链运营团队, 17 02月, 2025，浏览：
655 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | 7R-7952 | [2] | COVER | |
| 2. | 7R-7942 | [4] | CLAMP | |
| 3. | 5V-6152 | [4] | CLAMP | |
| 4. | 280-7262I | [1] | HOSE AS | |
| 5. | 277-4891I | [1] | HOSE AS | |
| 6. | 100-6623I | [1] | HOSE AS | |
| 7. | 281-1646I | [1] | HOSE AS | |
| 8. | 7R-7951 | [2] | PLATE | |
| 9. | 5P-4115C | [3] | WASHER-HARD(7.2X19X2-MM THK) | |
| 10. | 8T-3844CM | [1] | BOLT(M6X1X70-MM) | |
| 11. | 7X-2535M | [3] | BOLT(M6X1X60-MM) | |
| 12. | 178-3620 | [2] | STRAP-DUAL CLAMP | |
| 13. | 7X-7888CM | [4] | BOLT(M6X1X90-MM) | |
| 14. | 8T-4205C | [3] | WASHER-HARD(7.2X14.5X2-MM THK) | |
| 15. | 322-3271C | [2] | PLATE-SPACER | |
| | C | | CHANGE FROM PREVIOUS TYPE |
| | I | | REFER TO HYDRAULIC INFORMATION SYSTEM |
| | M | | METRIC PART |
