| Pos. | Part No | Qty | Parts name | Comments |
|---|---|---|---|---|
| 1. | 257-2029 | [2] | MOUNT AS | |
| 2. | 257-2030 | [2] | MOUNT AS | |
| 3. | 8T-4956M | [14] | BOLT(M12X1.75X35-MM) | |
| 4. | 8T-4223 | [14] | WASHER-HARD(13.5X25.5X3-MM THK) | |
| 258-6580FY | [1] | SENSOR GP-SONIC(AVERAGING SKI) | ||
| F | NOT SHOWN | |||
| M | METRIC PART | |||
| Y | SEPARATE ILLUSTRATION | |||
