卡特零件查询（8） 110-1546: LINES GP-BURNER
广数供应链运营团队, 17 02月, 2025，浏览：
658 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | 6V-8397 | [11] | SEAL-O-RING | |
| 2. | 8I-0708 I | [1] | HOSE AS | |
| 3. | 7X-0820 | [1] | TEE-UNION | |
| 4. | 6V-9168 | [1] | NUT (11/16-16-THD) | |
| 5. | 117-8571 I | [3] | HOSE AS | |
| 6. | 117-8572 I | [1] | HOSE AS | |
| 7. | 5P-4653 | [2] | CONNECTOR | |
| 8. | 2P-1279 | [2] | LOCKNUT (9/16-18-THD) | |
| 9. | 5P-8998 | [6] | FITTING | |
| 10. | 7B-0192 | [2] | CONNECTOR | |
| 11. | 8I-0400 | [3] | ADAPTER | |
| 12. | 8I-0716 | [2] | COUPLING | |
| 13. | 129-3078 | [2] | VALVE AS-SHUTOFF | |
| 14. | 8C-6868 | [4] | CONNECTOR | |
| 15. | 003-8747 | [2] | ELBOW | |
| 16. | 077-8184 | [2] | CLAMP | |
| 17. | 8C-8988 | [1] | ELBOW | |
| 18. | 5M-6213 | [2] | PLUG-PIPE | |
| 19. | 3S-2093 | [1] | STRAP-CABLE | |
| 20. | 9S-8927 | [1] | PLUG | |
| | I | | REFER TO HYDRAULIC INFORMATION SYSTEM |
