| | | [1] | SCREED VIBRATOR DRIVE HYDRAULIC PLUMBING |
| 1. | | [2] | COVER |
| 2. | B | | CABLE TIE (FOR HOSES) |
| 3. | | [20] | CLAMP |
| 4. | | [1] | HOSE ASSY, 1/2IN. J.I.C. X 162IN. |
| 5. | | [7] | ELBOW, 90 DEG DJ., 7/8IN.-14 STR. THD. X 1/2IN. J.I.C. |
| 6. | 8M-0547 | [7] | ELBOW, 90 DEG SWIVEL, 1/2IN. J.I.C. | |
| 7. | | [1] | HOSE ASSY., 1/2IN. J.I.C. X 216IN. |
| 8. | | [1] | HOSE ASSY., 1/2IN. J.I.C. X 96IN. |
| 9. | 5P-8228 | [2] | REDUCER, 5/8IN. X 1/2IN. J.I.C. | |
| 10. | | [2] | ELBOW, 45 DEG, 7/8IN.-14 STR. THD. X 5/8IN. J.I.C. |
| 11. | | [1] | VALVE, FLOW CONTROL |
| 12. | 8C-1790 | [1] | CONNECTOR, STR. 7/8IN.-14 STR. THD. X 3/4IN. J.I.C. | |
| 13. | | [1] | ELBOW, 90 DEG SWIVEL, 3/4IN. J.I.C. |
| 14. | 003-9163 | [1] | ELBOW, 90 DEG STREET, 3/4IN. N.P.T. | |
| 15. | | [1] | HOSE ASSY., 3/4IN. J.I.C. X 40IN. |
| 16. | | [1] | COUPLING, QUICK DISCONNECT, 3/4IN. N.P.T. |
| 17. | | [1] | PLUG, DUST |
| 18. | | [1] | NIPPLE, QUICK DISCONNECT, 3/4IN. N.P.T. |
| 19. | | [1] | COVER, DUST |
| 20. | | [1] | CONNECTOR, STR., 7/8IN.-14 STR. THD. X 3/4IN. N.P.T. |
| 21. | | [1] | ELBOW, 90 DEG, 3/4IN. J.I.C. X 3/4IN. N.P.T. |
| 22. | | [2] | CAPSCREW, HEX. HD., 5/16IN.-18 N.C. X 1IN. |
| 23. | 3B-4505 | [2] | LOCKWASHER, 5/16IN. | |
| 24. | | [3] | CONNECTOR, STR., 7/8IN.-14 STR. THD. X 1/2IN. J.I.C. |
| 25. | | [1] | HOSE ASSY., 1/2IN. J.I.C. X 207IN. |
| 26. | | [1] | HOSE ASSY., 1/2IN. J.I.C. X 188IN. |
| 27. | | [1] | HOSE ASSY., 1/2IN. J.I.C. X 40IN. |
