卡特零件查询（SE50） 451-3783: MOTOR GP-GEAR
广数供应链运营团队, 18 02月, 2025，浏览：
403 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | 419-5586 | [1] | NUT-JAM(M12X1.25-THD) | |
| 2. | 3B-4508 | [1] | LOCKWASHER | |
| 3. | 3E-4333 | [1] | KEY-WOODRUFF | |
| 4. | 199-7560J | [1] | RING-RETAINING | |
| 5. | 369-7900J | [1] | WASHER-BACKUP | |
| 6. | 195-3042 | [4] | BOLT-SOCKET HEAD(M10X1.5X115-MM) | |
| 7. | 369-7901J | [1] | SEAL-LIP TYPE | |
| 8. | 360-3678 | [2] | PLUG-O-RING | |
| 9. | 6V-3922 | [2] | SEAL-O-RING | |
| 10. | 150-5785 | [4] | DOWEL | |
| 11. | 7X-0608 | [4] | WASHER-HARD(10.2X16X2-MM THK) | |
| | | | |
| | | | PARTS SHOWN IN GRAPHIC(S) WITHOUT A REFERENCE NUMBER ARE NOT SERVICED SEPARATELY |
| | | | |
| | | | AVAILABLE REPAIR KIT(S): |
| | 445-8752J | [1] | KIT-SEAL | |
| | | | (INCLUDES PARTS MARKED "H" IN THE GRAPHIC) |
| | J | | KIT MARKED J SERVICES PART(S) MARKED J |
