卡特零件查询（434F2） 510-7948: CYLINDER GP-STICK
广数供应链运营团队, 18 02月, 2025，浏览：
354 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | 6V-8398 | [1] | SEAL-O-RING | |
| 2. | 324-0436 | [1] | ROD AS | |
| 3. | 324-0498 | [1] | PISTON AS | |
| | 161-7145J | [1] | SEAL-PISTON | |
| | 324-0497 | [1] | PISTON | |
| | 340-6272J | [2] | RING-WEAR | |
| | 340-9311J | [1] | SEAL-O-RING | |
| 4. | 324-0501 | [1] | CYLINDER AS | |
| | 334-9278 | [1] | TUBE AS | |
| 5. | 350-3842M | [2] | SETSCREW(M8X1.25X12.3-MM) | |
| 6. | 494-4313Y | [1] | HEAD GP-HYDRAULIC CYLINDER | |
| | | | |
| | 501-6692FJ | [1] | KIT-HYD CYLINDER SEAL(EXTENDABLE STICK) | |
| | 323-2465F | [1] | BUSHING | |
| | 338-2442F | [1] | SEAL-U-CUP | |
| | 340-9308F | [1] | SEAL-O-RING | |
| | 478-4173F | [1] | SEAL-WIPER | |
| | F | | NOT SHOWN |
| | J | | KIT MARKED J SERVICES PART(S) MARKED J |
| | M | | METRIC PART |
| | Y | | SEPARATE ILLUSTRATION |
