| Pos. | Part No | Qty | Parts name | Comments |
|---|---|---|---|---|
| 1. | 250-0270 | [1] | BRACKET AS | |
| 2. | 250-0273 | [1] | BRACKET AS | |
| 3. | 250-0278 | [1] | GUARD AS | |
| 4. | 7X-7729 | [4] | WASHER(11X25X3-MM THK) | |
| 5. | 8T-4121 | [4] | WASHER-HARD(11X21X2.5-MM THK) | |
| 6. | 8T-4186M | [4] | BOLT(M10X1.5X40-MM) | |
| 7. | 8T-4195M | [4] | BOLT(M10X1.5X30-MM) | |
| M | METRIC PART | |||
