Cat 320 Excavator Fault Codes
| Fault Code | Description |
|---|---|
| E0 | No Fault |
| E1 | Engine oil pressure too low |
| E2 | Engine water temperature too high |
| E3 | Hydraulic oil temperature too high |
| E4 | Battery voltage too high |
| E5 | Alternator P or W terminal disconnected |
| E6 | Speed sensor incorrectly installed or circuit open |
| E7 | Engine speed abnormal |
| E9 | Throttle motor feedback voltage too low |
| El0 | Throttle feedback sensor circuit short to power or open |
| E11 | Throttle feedback sensor short to ground |
| E12 | Throttle feedback sensor voltage unstable |
| E13 | Throttle motor circuit short to ground |
| E14 | Throttle motor not rotating or motor circuit short to power |
| E15 | Throttle backup switch in backup position or throttle motor circuit open |
| E16 | Proportional reducing valve short to ground |
| E17 | Proportional reducing valve circuit short to power |
| E18 | Proportional reducing valve circuit open |
| E25 | Water temperature sensor short to ground |
| E27 | Hydraulic oil temperature sensor short to ground |
| E31 | Engine speed signal received by controller differs from 10 set throttle dial values |
| E32 | Difference between throttle dial set value and actual speed exceeds lOOr/min |
| E33 | Data output circuit short to power |
| E34 | Throttle motor action lags throttle dial by 2.5s |
| E36 | Time for monitor to read signal from controller exceeds Is |
| E37 | Monitor RAM abnormal |
| E38 | Controller receives error signal from monitor |
| E39 | Controller generates its own error signal |
| E40 | Controller memory error |
| E41 | Controller does not match machine model |
| E48 | Engine stalled |
| E48 | Engine stalled |
Cat 320B Excavator Fault Codes
| Fault Code | Description |
|---|---|
| 1301 | Engine oil pressure too low |
| 1302 | Engine coolant temperature too high |
| 1303 | Hydraulic oil temperature too high |
| 1304 | Air inlet filter clogged |
| 1305 | Battery voltage abnormal |
| 2201 | Governor actuator feedback sensor connected to battery voltage open or shorted |
| 2202 | Governor actuator feedback sensor connected to chassis ground shorted |
| 2301 | Governor actuator feedback signal unstable |
| 2302 | Governor actuator feedback signal deviated |
| 2303 | Governor actuator does not move |
| 2304 | Calibration data error |
| 3201 | Monitor RAM abnormal |
| 4101 | Too much power supplied to controller (43 volts) |
| 4102 | PRV current too high |
| 4103 | PRV open circuit |
| 4104 | Monitor power (digital output) overcurrent |
| 4105 | Overcurrent in digital output (ditch solenoid valve) |
| 4106 | Overcurrent in digital output (fine control solenoid valve) |
| 4107 | Overcurrent in digital output (travel speed change solenoid valve) |
| 4108 | Overcurrent in digital output (travel alarm) |
| 4109 | Spare solenoid coil 1 (digital output) overcurrent |
| 410A | Overcurrent in digital output (turntable brake solenoid valve) |
| 410B | Spare solenoid coil 2 (digital output) overcurrent |
| 4201 | Engine speed abnormal |
| 4202 | Engine coolant temperature sensor connected to chassis ground shorted |
| 4203 | Hydraulic oil temperature sensor connected to chassis ground shorted |
| 4204 | Pump delivery pressure PWM sensor connected to chassis ground shorted |
| 4205 | Spare PWM sensor 1 connected to chassis ground shorted |
| 4206 | Spare PWM sensor 2 connected to chassis ground shorted |
| 4207 | Pump delivery pressure PWM sensor open circuit when powered on |
| 420A | Fuel sensor connected to chassis ground open circuit |
| 420B | Fuel sensor connected to battery voltage open or shorted |
| 420C | Power supply too low (below 23 volts) |
| 420D | Power supply too high (above 32 volts) |
| 420E | Engine speed knob not in one of the 10 specified positions |
| 4301 | Alternator and speed sensor data mismatch 1 (alternator abnormal) |
| 4302 | Alternator and speed sensor data mismatch 2 (speed sensor abnormal) |
| 4303 | Engine stalled |
| A201 | Monitor communication abnormal |
| A202 | Monitor takes too long to respond to controller signal |
| A203 | Communication abnormal in controller |
| A20D | ADEM communication interrupted |
Cat 330C Excavator Fault Codes
| Fault Code | Description |
|---|---|
| 0001 | #1 Cylinder Injector Solenoid Valve |
| 0002 | #2 Cylinder Injector Solenoid Valve |
| 0003 | #3 Cylinder Injector Solenoid Valve |
| 0004 | #4 Cylinder Injector Solenoid Valve |
| 0005 | #5 Cylinder Injector Solenoid Valve |
| 0006 | #6 Cylinder Injector Solenoid Valve |
| 0041 | 8V DC Power Supply |
| 0042 | Injector Actuation Control Valve |
| 0091 | Throttle Position Signal |
| 0094 | Fuel Pressure Sensor |
| 0100 | Engine Oil Pressure Sensor |
| 0110 | Engine Coolant Temperature Sensor |
| 0164 | Injector Actuation Pressure |
| 0168 | System Voltage |
| 0172 | Intake Manifold Air Temperature |
| 0175 | Engine Oil Temperature Sensor |
| 0190 | Engine Speed Sensor |
| 0253 | Personality Module |
| 0261 | Engine Timing Calibration |
| 0262 | 5V Sensor DC Power Supply |
| 0268 | Check Programmable Parameters |
| 0273 | Turbocharger Outlet Pressure Sensor |
| 0274 | Atmospheric Pressure Sensor |
| 0286 | Oil Lamp |
| 0342 | Secondary Engine Speed Sensor |
| 0617 | Air Intake Heater Relay |
| 1627 | Fuel Pump Relay |
| 0091 | Throttle Position Signal |
| 0096 | Fuel Level Sensor |
| 0110 | Engine Coolant Temperature Sensor |
| 0167 | Alternator |
| 0168 | Key Switch Voltage |
| 0190 | Speed Sensor |
| 0248 | CAT Data Link |
| 0286 | Engine Oil Pressure Low Signal |
| 0374 | Swing Brake Solenoid |
| 0376 | Travel Alarm |
| 0581 | Power Shift Proportional Reducing Valve |
| 0586 | Engine Speed Dial Switch |
| 0587 | Regulator Actuator Feedback Signal |
| 0590 | Engine Controller |
| 0598 | Walking Speed Solenoid Valve |
| 0600 | Hydraulic Oil Temperature Sensor |
| 1161 | Pump Pressure |
| 1162 | Pump Pressure |
| 1524 | Negative Flow Control Proportional Solenoid Valve |
| 1525 | Straight Travel Solenoid Valve |
| 1590 | Negative Flow Control Proportional Solenoid Valve |
| FMI Fault Codes Description | |
| 0 | Data valid but above normal operating range |
| 1 | Data valid but below normal operating range |
| 2 | Data erratic, intermittent, or incorrect |
| 3 | Voltage above normal or shorted high |
| 4 | Voltage below normal or shorted low |
| 5 | Current below normal or open circuit |
| 6 | Current above normal or grounded circuit |
| 7 | Mechanical system not responding correctly |
| 8 | Abnormal frequency, pulse width, or period |
| 9 | Abnormal update rate |
| 10 | Abnormal rate of change |
| 11 | Failure mode not identifiable |
| 12 | Bad device or component |
| 13 | Out of calibration |
| 14-31 | Reserved |
Cat 320D Excavator Fault Codes
| Fault Code | Description |
|---|---|
| 00 | Data valid, but above normal operating range |
| 01 | Data valid, but below normal operating range |
| 02 | Signal error (data unstable, intermittent, or erroneous) |
| 03 | Voltage above normal value |
| 04 | Voltage below normal value |
| 05 | Current below normal value |
| 06 | Current above normal value |
| 07 | Mechanical system response abnormal |
| 08 | Signal abnormal (frequency, pulse width, or cycle abnormal) |
| 9 | Update abnormal |
| 10 | Rate of change abnormal |
| 11 | Failure mode not identifiable |
| 12 | Device or component damaged |
| 13 | Calibration failed |
| 14 | Parallel metering fault |
| 15 | Parallel metering fault |
| 16 | Parallel metering invalid |
| 17 | Module (program) did not respond |
| 18 | Sensor power failure |
| 19 | Receiving network data error |
| 20 | Parallel metering fault |
| 0041 | 8V Power Supply |
| 0096 | Fuel Level Sensor |
| 0110 | Engine Coolant Temperature Sensor |
| 0167 | Alternator |
| 0168 | System Power Supply |
| 0190 | Engine Speed Sensor |
| 0246 | CAN Data Link |
| 0247 | SAE J1939 Data Link |
| 0248 | Caterpillar Data Link |
| 0254 | Electronic Control Module (ECM) |
| 0262 | sv Sensor Power Supply |
| 0271 | Alarm Device |
| 0291 | Engine Cooling Fan Solenoid Valve |
| 0362 | Engine Variable Speed Fan Control Solenoid Valve |
| 0374 | Swing Brake Solenoid Valve |
| 0485 | Engine Fan Reversing Solenoid Valve |
| 0544 | Engine Cooling Fan Variable Speed Solenoid Valve |
| 0581 | Power Shift Pressure Proportional Solenoid Valve |
| 0586 | Engine Throttle Dial |
| 0588 | Instrument Display System |
| 0590 | ECM |
| 0598 | Walking Speed Conversion Solenoid Valve |
| 0600 | Hydraulic Oil Temperature Sensor |
| 0735 | Heavy Lift Solenoid Valve |
| 1129 | Right Attachment Pedal Sensor |
| 1130 | Left Attachment Pedal Sensor |
| 1160 | Hydraulic Lock Solenoid Valve |
| 1178 | Mechanical Overload Alarm Pressure Sensor |
| 1522 | No. 2 Relief Valve Check Valve Solenoid Valve |
| 1523 | No. 1 Relief Valve Check Valve Solenoid Valve |
| 1525 | Straight Travel Solenoid Valve |
| 1590 | Main Hydraulic Pump Output Limiting Pressure Solenoid Valve |
| 1593 | No. 1 Attachment Valve Extend Pressure Solenoid Valve |
| 1594 | No. 2 Attachment Valve Extend Pressure Solenoid Valve |
| 1595 | No. 3 Attachment Valve Pressure Solenoid Valve |
| 1596 | No. 1 Attachment Valve Retract Pressure Solenoid Valve |
| 1597 | No. 2 Attachment Valve Retract Pressure Solenoid Valve |
| 1598 | No. 3 Attachment Valve Cancel Pressure Solenoid Valve |
| 1609 | F2 Mode Valve Circuit Feedback Pressure Sensor |
| 1657 | Left Joystick Top Button |
| 1658 | Right Joystick Top Button |
| 1665 | No. 1 Adjustable Pressure Relief Valve Solenoid Valve |
| 1666 | No. 2 Adjustable Pressure Relief Valve Solenoid Valve |
| 1931 | Optional Circuit |
| 2265 | Pump Output Pressure Sensor l |
| 2266 | Pump Output Pressure Sensor 2 |
| 2275 | Breaker Return Oil Line Control (Direct to Oil Tank) Solenoid Valve |
| 2280 | Travel Alarm Relay |
| 2300 | Switch Panel |
Cat C9 Engine Fault Codes
| Fault Code | Description |
|---|---|
| 112 | Accelerator Pedal 1 Fault |
| 113 | Accelerator Pedal and Brake Pedal Signals Unreliable |
| 116 | Clutch Signal Fault |
| 117 | Brake Pedal Fault |
| 119 | Terminal 15 Fault |
| 11C | Fuel Filter Water Separator |
| 211 | Vehicle Speed Sensor Fault |
| 215 | Cruise Control Button Irreversible Fault |
| 125 | Main Relay 2 Failure |
| 126 | Battery Voltage Fault |
| 127 | Engine Brake Failure |
| 128 | Main Relay 1 Short Circuit to Battery |
| 129 | Main Relay 3 Fault |
| 12A | Engine Brake (Main Relay 4) Fault |
| 12B | Air Heater 1 Power Stage Fault |
| 12E | Preheat Control System Fault |
| 225 | Main Relay Failure (Interruption After Stop) |
| 228 | Main Relay 1 Short Circuit to Ground |
| 131 | Coolant Temperature Sensor |
| 132 | Coolant Temperature Sensor Dynamic Fault |
| 133 | B Intake Temperature Sensor |
| 134 | Intake Pressure Sensor |
| 135 | Fuel Temperature Sensor |
| 136 | Common Rail Pressure Sensor |
| 137 | Common Rail Pressure Limiting Valve |
| 138 | Oil Pressure Sensor |
| 13A | Oil Temperature Sensor |
| 232 | Coolant Temperature (Monitoring) |
| 236 | Common Rail Pressure Sensor Deviation Monitoring |
| 238 | Oil Pressure Too Low |
| 23A | Oil Temperature Too High |
| 141 | Crankshaft Speed Sensor |
| 142 | Camshaft Sensor Signal Only |
| 143 | Camshaft Sensor |
| 144 | Camshaft Sensor and Crankshaft Sensor Signal Deviation Exceeds Limit |
| 149 | Fuel Filter Heater Fault |
| 14A | Engine Compartment Start Button Stuck |
| 14D | Note: Engine Overspeed Protection |
| 24A | Engine Compartment Stop Button Stuck |
| 152 | Common Rail Pressure Positive Deviation Too High and Fuel Flow Set Value Too High |
| 153 | Common Rail Pressure Negative Deviation Too High (Minimum Flow) |
| 154 | Common Rail Pressure Below Minimum Limit |
| 155 | Common Rail Pressure Greater Than Maximum Limit |
| 156 | Common Rail Fuel Pressure Drop Rate Too High |
| 157 | S Overspeed Common Rail Metering Valve Not Authentic |
| 158 | Common Rail Metering Unit Fuel Flow Setting Point Too Low |
| 159 | Common Rail Oil Pump Metering Valve Power Stage Fault |
| 259 | Common Rail Metering Valve Positive Short Circuit |
| 359 | Common Rail Metering Valve Negative Short Circuit |
| 161 | Cylinder 1 Injector Fault |
| 162 | Cylinder 2 Injector Fault |
| 163 | Cylinder 3 Injector Fault |
| 164 | Cylinder 4 Injector Fault |
| 165 | Cylinder 5 Injector Fault |
| 166 | Cylinder 6 Injector Fault |
| 167 | Cylinder 1 Injector Open Circuit |
| 168 | Cylinder 2 Injector Open Circuit |
| 169 | Cylinder 3 Injector Open Circuit |
| 16A | Cylinder 4 Injector Open Circuit |
| 16B | Cylinder 5 Injector Open Circuit |
| 16C | Cylinder 6 Injector Open Circuit |
| 16E | Minimum Number of Injection Cylinders Not Reached |
| 171 | Injector Wiring Harness 1 Fault |
| 172 | I Injector Wiring Harness 2 Fault |
| 17C | ECU Injector Control Unit: CY33X(1) Fault |
| 27C | ECU Injector Control Unit: CY33X(2) Fault |
| 19E | Limit Torque Value to Reduce Smoke |
| 29D | Torque Limitation Due to Negative Torque |
| 39E | Torque Limitation Due to Turbocharger Protection |
| 49E | Torque Limitation on Engine Protection |
| 69E | Torque Limitation on Injection Amount of Fuel Injection System |
Looking for reliable solutions for your engineering machinery parts, heavy-duty truck parts, agricultural machinery parts, and auto parts needs? Growshine International specializes in the import and export of high-quality components for a wide range of vehicles and equipment. We understand the importance of minimizing downtime and ensuring your machinery operates at peak performance. This guide to Caterpillar excavator fault codes can help you diagnose issues quickly.
Our extensive catalog includes parts for major brands like Caterpillar (Cat), Komatsu, John Deere, Volvo, Hitachi, Doosan, Hyundai, Kobelco, Sany, LiuGong, XCMG, Zoomlion, Cummins, Perkins, Isuzu, and many more. Whether you need engine components, hydraulic parts, electrical systems, or undercarriage parts, Growshine International is your trusted partner.
Explore our wide range of engineering machinery parts including: Caterpillar excavator spare parts supplier, Komatsu heavy equipment engine components, John Deere tractor replacement parts online, Volvo construction equipment parts, Hitachi excavator aftermarket parts, Doosan construction machinery parts, Hyundai excavator parts, Kobelco excavator parts, Sany excavator parts, LiuGong wheel loader parts, XCMG crane parts, Zoomlion concrete pump parts, Cummins engine parts, Perkins engine parts, Isuzu engine parts, heavy-duty truck parts import export, agricultural machinery parts trading, auto parts worldwide shipping, reliable excavator parts distributor, global supplier of construction equipment components.
We offer a comprehensive selection of components such as: excavator engine oil pressure sensor, Caterpillar hydraulic oil temperature sensor, Komatsu engine speed sensor, Volvo throttle motor replacement, Hitachi pressure reducing valve for excavator, Doosan water temperature sensor online, Hyundai battery voltage regulator for heavy equipment, Kobelco fuel filter assembly, Sany speed sensor for construction machinery, LiuGong hydraulic pump for wheel loader, XCMG swing motor for crane, Zoomlion engine coolant temperature sensor, Cummins common rail pressure sensor, Perkins fuel injector for sale, Isuzu alternator for truck engine, Cat 320 engine parts, Cat 330C hydraulic components, Cat 320D electrical parts, Cat C9 fuel system parts, heavy truck engine oil cooler.
