| 1. |
ZA104765
|
[4] |
BELT
|
IH
- roller, endless, 11 inch (279 MM) wide (Alternate part is ZA104712) Superseded by part number: 225969A1
|
| 2. |
ZA104712
|
[4] |
BELT
|
IH
- Roller, 11 inch (279 mm) wide (Alternate part is ZA104765) Superseded by part number: 700711081, 700724729
|
| 3. |
ZA102977
|
[1] |
PIN
|
IH
- belt
|
| 4. |
ZA105926
|
[1] |
ROLLER
|
CAS
ASSEMBLY - number 1
|
| 5. |
ZA105916
|
[2] |
ROLLER
|
CAS
ASSEMBLY - number 2 and 3
|
| 6. |
ZA105918
|
[1] |
ROLLER
|
CAS
ASSEMBLY - number 4 Superseded by part number: 228695A1, 251880A1
|
| 7. |
ZA105980
|
[1] |
DIVIDER
|
CAS
- belt
|
| 8. |
ZA105913
|
[1] |
STRIPPER
|
CAS
SCRAPER - roller Superseded by part number: ZA106781
|
| 9. |
ZA105794
|
[7] |
BALL BEARING
|
CAS
BEARING - hex bore, 1.25 inch (32 MM) ID Superseded by part number: 47442495
|
| 10. |
ZA105796
|
[4] |
COLLAR
|
CAS
- bearing
|
| 14. |
ZA105799
|
[3] |
COLLAR
|
CAS
- bearing
|
| 15. |
ZA105946
|
[1] |
PIVOT
|
CAS
- idler
|
| 16. |
ZA104905
|
[1] |
SHAFT
|
IH
ASSEMBLY - pivot, left
|
| 17. |
ZA104906
|
[1] |
SHAFT
|
IH
ASSEMBLY - pivot, right
|
| 18. |
ZA761370
|
[2] |
SPRING
|
IH
ASSEMBLY - extension
|
| 19. |
1281009C1
|
[1] |
INSERT
|
IH
- spring
|
| 20. |
120378
|
[4] |
NUT,Hex, 1/2" - 13, Gr 5
|
IH
NUT, 1/2"-13, G5 Superseded by part number: 280431
|
| 21. |
NLS
|
[2] |
NO LONGER SERVICED
|
BAS
- flat, 17/32 x 1-1/16 x 5/64 inch (13 x 27 x 2 MM)
|
| 22. |
445608
|
[2] |
BOLT,Hex, 1/2" - 13 x 5 1/2", Gr 5
|
IH
- hex, 1/2 NC x 5-1/2 inch Superseded by part number: 88576
|
| 26. |
27908R1
|
[1] |
BOLT,1/2" x 1 1/4", Gr 8
|
CAS
- hex, 1/2 NC x 1-1/4 inch, grade 8
|
| 27. |
357020R1
|
[1] |
WASHER
|
IH
- flat, 17/32 x 1-3/4 x 1/4 inch (13 x 44 x 6 MM)
|
| 28. |
ZA104593
|
[1] |
HUB
|
IH
- splined
|
| 29. |
ZA104227
|
[1] |
SPROCKET ASSY.
|
IH
SPROCKET - 30 tooth
|
| 30. |
96328C1
|
[1] |
BALL BEARING,40mm ID x 80mm OD x 22mm W
|
CAS
- ball, 1.57 inch (40 MM) ID
|
| 31. |
ZA104841
|
[1] |
HOUSING
|
IH
- bearing
|
| 34. |
271723
|
[1] |
SNAP RING,Hex, 5/8" - 11 x 2", Gr 5
|
NNA
- hex, 5/8 NC x 2 inch Superseded by part number: 413-1032, 413-1032, NLS
|
| 35. |
541857R92
|
[1] |
SPROCKET,15T
|
IH
ASSEMBLY - idler (Includes bearing)
|
| 36. |
67872C1
|
[1] |
WASHER
|
IH
- flat, 21/32 x 1-1/4 x 1/4 inch (17 x 32 x 6 MM)
|
| 37. |
1281008C1
|
[1] |
SPRING
|
IH
- extension
|
| 38. |
ZA104649
|
[1] |
ARM
|
IH
ASSEMBLY - idler sprocket
|
| 39. |
96315C1
|
[1] |
BRONZE BUSHING
|
IH
BUSHING - idler arm
|
| 40. |
NSS
|
[1] |
NOT SOLD SEPARAT
|
CON
CHAIN ASSEMBLY - roller 10 to roller 4 (Use 151 links from bulk chain 611362R1, and 1 connecting link 574532R91)
|
| . . |
611362R91
|
[1] |
CHAIN (AG)
|
IH
CHAIN - 10 foot (3 M) roll Superseded by part number: 611362R91X
|
| . . |
574532R91
|
[1] |
CLIP, SPRING
|
IH
LINK - chain, connecting Superseded by part number: 241-1316
|
| 41. |
1254050C1
|
[1] |
TOOL
|
IH
LACER - belt, 6 inch (152 MM) Superseded by part number: 828459
|
| 44. |
667486R1
|
[2] |
BOLT
|
IH
BOLT - hex, special
|
| 45. |
180183
|
[4] |
BOLT,Hex, 1/2" - 13 x 2 1/4", Gr 5
|
IH
- hex, 1/2 NC x 2-1/4 inch Superseded by part number: 113-441
|
| 46. |
9413956
|
[4] |
LOCK NUT,1/2"-13, GB
|
IH
NUT - hex lock, 1/2 inch NC Superseded by part number: 231-4138
|
| 47. |
1336821C1
|
[8] |
SCREW,Lock, Flat Csk Hd, 3/8" - 16 x 125mm
|
CAS
BOLT - hex socket flat head, 3/8 NC x 1 inch
|
| . . |
208790C1
|
[1] |
PACKAGE
|
IH
KIT - repair, belt (Box of lacing hooks)
|
