神钢零件查询(4BD1) - ISUZU DIESEL ENGINE - K905 MARK II EXCAVATORS (1/06-12/07) (01-026) - STARTER (NIKKO) (P/N-581100-1710) Kobelco
广数供应链运营团队, 14 02月, 2025，浏览：
777 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | VI5811001710 | [1] | STARTER ASM, 12V-2.5KW | |
| . . | VI1811002270 | [1] | STARTER ASM, 12V-2.5KW | |
| . . | VI5811001790 | [1] | STARTER ASM, 12V-2.5KW | |
| 1. | VI1811290400 | [1] | PIN, LEVER | |
| 2. | VI1811270200 | [1] | LEVER ASM, SHIFT | |
| 2-1. | VI5811270170 | [1] | LEVER ASM, SHIFT | |
| 3. | VI5094000250 | [1] | NUT | KOB Superseded by part number: 5094000250 |
| 4. | VI1811510510 | [1] | SWITCH ASM, MAGNETIC | |
| 4-1. | VI1811510630 | [1] | SWITCH ASM, MAGNETIC | |
| 4-2. | VI5811510460 | [1] | SWITCH ASM, MAGNETIC | |
| 5. | VI1811290920 | [1] | PLUNGER ASM | |
| 5-1. | VI5811291910 | [1] | PLUNGER ASM | |
| 6. | VI1812290940 | [1] | BUSH, INSULATOR | |
| 6-1. | VI9821161400 | [1] | BUSH, INSULATOR | |
| 7. | VI1811290940 | [1] | CONNECTOR, MOVING | |
| 7-1. | VI5811291930 | [1] | CONNECTOR, MOVING | |
| 6. | VI1811180090 | [1] | HOLDER | |
| 8-1. | VI5811180190 | [1] | HOLDER | |
| 9. | VI1811290950 | [1] | TERMINAL ASM. | |
| 9-1. | VI1811294370 | [1] | TERMINAL ASM. | |
| 9-2. | VI5811291940 | [1] | TERMINAL ASM. | |
| 10. | VI1811290960 | [1] | WASHER, INSULATOR | |
| 10-1. | VI9821161420 | [1] | WASHER, INSULATOR | |
| 11. | VI1811291040 | [2] | CLIP, RING | |
| 11-1. | VI5811291490 | [2] | CLIP, RING | |
| 12. | VI1811710270 | [1] | SWITCH ASM. | |
| 12-1. | VI1825530290 | [1] | SWITCH ASM. | |
| 13. | VI1811150430 | [1] | BRACKET ASM., REAR | |
| 13-1. | VI5811150400 | [1] | BRACKET ASM , REAR | |
| 14. | VI1811170030 | [4] | SPRING, BRUSH | |
| 14-1. | VI1811170140 | [4] | SPRING, BRUSH | |
| 15. | VI5811190330 | [4] | BRUSH ASM. | |
| 15-1. | VI5811160390 | [4] | BRUSH ASM. | |
| 16. | VI1812141000 | [1] | BRACKET, REAR | |
| 16-1. | VI5811150410 | [1] | BRACKET, REAR | |
| 17. | VI1811290410 | [1] | METAL, REAR | |
| 17-1. | VI5811292150 | [1] | BEARING, BALL | |
| 18. | VI1811291020 | [1] | TUBE, INSULATE | |
| 19. | VI1811160120 | [1] | BAR, CONNECTOR | |
| 20. | VI1811291030 | [2] | WASHER, INSULATE | |
| 21. | VI1811180180 | [1] | HOLDER ASM, BRUSH | |
| 21-1. | VI5811180240 | [1] | HOLDER ASM, BRUSH | |
| 22. | VI1811291010 | [2] | WASHER, INSULATE | |
| 23. | VI1811290980 | [1] | TUBE, INSULATE | |
| 24. | VI5811130080 | [1] | BRACKET ASM, FRONT | |
| 24-1. | VI5811130400 | [1] | BRACKET ASM, FRONT | |
| 24-2. | VI5811130410 | [1] | BRACKET ASM, FRONT | |
| 25. | VI1811290410 | [1] | METAL,FRONT | |
| 25-1. | VI5811292200 | [1] | SET OF STD MAIN BRGS | KOBMETAL, FRONT |
| 26. | VI5811220030 | [1] | CLUTCH ASM., PINION | |
| 26-1. | VI5811290190 | [1] | CLUTCH ASM, PINION | |
| 27. | VI1811291490 | [2] | METAL | |
| 27-1. | VI5811292170 | [1] | METAL | |
| 28. | VI1811180330 | [1] | BRACKET ASM, CENTER | |
| 28-1. | VI5811130420 | [1] | BRACKET ASM, CENTER | |
| 28-2. | VI5811130430 | [1] | BRACKET ASM, CENTER | |
| 29. | VI1811290300 | [1] | METAL, CENTER | |
| 29-1. | VI5811292160 | [1] | BEARING, BALL | |
| 30. | VI1811290350 | [4] | SCREW, DISH | |
| 30-1. | VI5811292210 | [4] | SCREW, DISH | |
| 31. | VI1811120270 | [1] | COIL ASM., FIELD | |
| 31-1. | VI5811120250 | [1] | COIL ASM., FIELD | |
| 32. | VI1811290310 | [2] | WASHER | |
| 33. | VI5811290340 | [2] | BOLT | |
| 34. | VI1811210310 | [1] | ARMATURE ASM. | |
| 34-1. | VI5811210350 | [1] | ARMATURE ASM. | |
| 35. | VI1811290360 | [1] | STOPPER, PINION | |
| 35-1. | VI5811290550 | [1] | PIN | KOBSTOPPER, PINION Superseded by part number: 5811290550 |
| 36. | VI1811290330 | [1] | WASHER, INSULATOR | |
| 36-1. | VI5811291580 | [1] | WASHER, INSULATOR | |
| 37. | VI1811291180 | [1] | WASHER | |
| 37-1. | VI1811291070 | [1] | WASHER | |
| 37-2. | VI5811291600 | [1] | WASHER | |
| 38. | VI9821154770 | [1] | WASHER | |
| 39. | VI1811290270 | [2] | WASHER | |
| 39-1. | VI1811291540 | [2] | WASHER | |
| 40. | VI1811290280 | [1] | WASHER, INSULATOR | |
| 52. | VI1811292750 | [1] | SEAL KIT, STARTER | |
