神钢零件查询(4BD1) - ISUZU DIESEL ENGINE - K905 MARK II EXCAVATORS (1/06-12/07) (01-027) - STARTER (NIKKO) (P/N-581100-1640) Kobelco
广数供应链运营团队, 14 02月, 2025，浏览：
903 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | VI5811001640 | [1] | STARTER ASM, 24V-3.5KW | |
| . . | VI5811001930 | [1] | STARTER MOTOR | KOBSTARTER ASM, 24V-3.5KW Superseded by part number: 76554716 |
| 1. | VI1811290400 | [1] | PIN, LEVER | |
| 2. | VI5811270170 | [1] | LEVER ASM, SHIFT | |
| 3. | VI5094000250 | [1] | NUT | KOB Superseded by part number: 5094000250 |
| 4. | VI5811510380 | [1] | SWITCH SWITCH ASM, MAGNETIC | SWITCH SWITCH ASM, MAGNETIC |
| 6. | VI5811590040 | [1] | WIRE, LEAD CONNECT | |
| 7. | VI5811291740 | [1] | WASHER, INSULATE | |
| 8. | VI5811291730 | [1] | BUSH, INSULATE | |
| 9. | VI1811170140 | [4] | SPRING, BRUSH | |
| 10. | VI5811160320 | [2] | BRUSH ASM., (-) | |
| 11. | VI5811180200 | [1] | HOLDER, BRUSH | |
| 12. | VI5811150320 | [1] | BRACKET ASM, RR. | |
| 13. | VI5811190180 | [2] | METAL, FRT.& RR. | |
| 14. | VI5812291140 | [2] | WASHER | |
| 15. | VI5811291720 | [2] | BOLT, THROUGH | |
| 16. | VI5811130340 | [1] | BRACKET ASM.FRT. | |
| 17. | VI5811190180 | [1] | METAL, FRT. | |
| 18. | VI5811220170 | [1] | COUPLING | KOBCLUTCH ASM, PINION |
| 19. | VI5811291710 | [1] | METAL, CLUTCH.PINION | |
| 20. | VI5811140190 | [1] | BRACKET ASM., CENTER | |
| 21. | VI5811190080 | [1] | METAL, CENTER | |
| 22. | VI1811290430 | [4] | SCREW, DISH | |
| 23. | VI5811210270 | [1] | FITTING | KOBARMATURE ASM. Superseded by part number: 5811210270 |
| 24. | VI5811290550 | [1] | PIN | KOBSTOPPER, PINION Superseded by part number: 5811290550 |
| 25. | VI5095030450 | [1] | WASHER | |
| 26. | VI5811280330 | [1] | WASHER | |
| 27. | VI9821251930 | [2] | PISTON RING SET | KOBRING.CLIP Superseded by part number: 9821251930 |
| 28. | VI5811280340 | [1] | WASHER | |
| 29. | VI5811280280 | [2] | WASHER, ADJ. | |
| 30. | VI5095030460 | [1] | WASHER, INSULATOR | |
| 31. | VI5811120200 | [1] | COIL ASM, FIELD | |
| 32. | VI5811160310 | [2] | BRUSH ASM., (+) | |
| 33. | VI5825530680 | [1] | THERMOSTAT | KOBSWITCH Superseded by part number: 1825530260 |
| 34. | VI5811292660 | [1] | BUSH,GUM | |
