神钢零件查询(4BD1) - ISUZU DIESEL ENGINE - K905 MARK II EXCAVATORS (1/06-12/07) (01-028) - STARTER (NIKKO) (P/N-1811002450) Kobelco
广数供应链运营团队, 14 02月, 2025，浏览：
340 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | VI1811002450 | [1] | STARTER ASM, 12V-3KW | |
| 1. | VI1811290400 | [1] | PIN, LEVER | |
| 2. | VI9821253410 | [2] | WASHER, SEAL | |
| 3. | VI5811270170 | [1] | LEVER ASM., SHIFT | |
| 4. | VI5094000250 | [1] | NUT | KOB Superseded by part number: 5094000250 |
| 5. | VI1811510750 | [1] | SWITCH ASH., MAG. | |
| 6. | VI5811291460 | [1] | PLUNGER ASM. | |
| 7. | VI1811295220 | [1] | BUSH, INSULATE | |
| 8. | VI5811291480 | [1] | CONTACTOR, MOVING | |
| 9. | VI1811295230 | [1] | WASHER, INSULATE | |
| 10. | VI5811180190 | [1] | HOLDER | |
| 11. | VI5811291490 | [2] | CLIP RING | |
| 12. | VI1811295240 | [1] | TERMINAL ASM. | |
| 13. | VI5811291510 | [2] | WASHER | |
| 14. | VI5811291520 | [2] | BOLT | |
| 15. | VI1811294190 | [2] | BOLT | |
| 16. | VI1811710420 | [1] | SWITCH ASM, STARTE RELY | |
| 17. | NSS | [1] | NOT SOLD SEPARAT | CONHOLDER |
| 18. | NSS | [1] | NOT SOLD SEPARAT | CONBOLT |
| 19. | VI8941780460 | [3] | BOLT | |
| 20. | VI8944188420 | [1] | TIRMINAL ASM. | |
| 21. | VI8944188450 | [1] | BRACKET ASM. REAR | |
| 22. | VI5811170190 | [4] | SPRING | KOBBRUSH |
| 23. | VI1811180450 | [1] | HOLDER ASM,BRUSH | |
| 24. | VI8944188460 | [1] | BRACKET, REAR | |
| 25. | VI9881202770 | [1] | WASHER, REAR | |
| 26. | NSS | [1] | NOT SOLD SEPARAT | CONSCREW |
| 27. | VI5811291980 | [2] | WASHER | |
| 28. | VI5811292410 | [2] | BOLT | |
| 29. | VI1812291140 | [2] | WASHER | |
| 30. | VI1811292920 | [2] | BOLT | |
| 31. | VI8944188550 | [1] | BRACKET ASM, FRONT | |
| 32. | VI1811293970 | [1] | METAL | |
| 33. | VI5811291440 | [2] | RING, CLIP | |
| 34. | VI5811291450 | [1] | STOP | KOBSTOPPER, PINION Superseded by part number: 289575A1 |
| 35. | VI8944188540 | [1] | CLUTCH ASM | |
| 36. | VI8944188560 | [1] | BRACKET, CENTER | |
| 37. | VI8944188530 | [1] | SHAFT ASM. | |
| 38. | VI8944188490 | [1] | BEARING | KOBBEARING, BALL |
| 39. | VI5811291600 | [1] | WASHER | |
| 40. | VI5811291590 | [1] | WASHER | |
| 41. | VI5811291580 | [1] | WASHER, INSULATE | |
| 42. | VI8944188580 | [1] | BRACKET, CENTER | |
| 43. | VI5811292400 | [4] | SCREW | |
| 44. | VI5811291560 | [1] | SET OF THRUST WASHER | KOBWASHER |
| 45. | VI8944188410 | [1] | ARMATURE ASM. | |
| 46. | VI1811295310 | [1] | BEARING, BALL | |
| 47. | VI1811295320 | [1] | BEARING, BALL | |
| 48. | VI1811295330 | [1] | COIL ASM, FIELD | |
| 49. | VI8944188430 | [4] | BRUSH | |
| 50. | VI8944188520 | [1] | SEAL ASM. | |
